卡特零件查询（730） 502-6415: HARNESS AS-CAB
广数供应链运营团队, 15 02月, 2025，浏览：
121 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 374-7465 | [2] | CAP-SEAL | |
| | 374-7466 | [1] | CAP-SEAL | |
| | 374-7468 | [1] | CAP-SEAL | |
| | 228-5856 | [6] | CONNECTOR(10-PIN) | |
| | 211-6807 | [1] | COVER-CONNECTOR | |
| | 339-2958 | [1] | GASKET | |
| | 203-9007 | [1] | NUT(1-1/2-18-THD) | |
| | 211-0052 | [1] | NUT(1-11/16-18-THD) | |
| | 9X-3401 | [11] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | | | -OR- |
| | 126-1767 | [11] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | 9X-3401 | [28] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 176-2947 | [2] | KIT-CONNECTING PLUG(4-PIN) | |
| | | | (EACH INCLUDES PLUG AS & WEDGE) |
| | 230-5010 | [2] | PLUG AS-CONNECTOR(6-PIN) | |
| | | | (EACH INCLUDES) |
| | 455-0707 | [1] | SEAL-CONNECTOR | |
| | 231-2295 | [2] | PLUG AS-CONNECTOR(8-PIN) | |
| | | | (EACH INCLUDES) |
| | 455-0708 | [1] | SEAL-CONNECTOR | |
| | 331-4224 | [1] | KIT-CONNECTING PLUG(6-PIN) | |
| | 331-4226 | [3] | KIT-CONNECTING PLUG(2-PIN) | |
| | 155-2270 | [3] | KIT-CONNECTING PLUG(2-PIN) | |
| | 155-2271 | [2] | KIT-CONNECTING PLUG(4-PIN) | |
| | 155-2274 | [2] | KIT-CONNECTING PLUG(6-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE, & INTERFACE SEAL) |
| | | [1] | PLUG AS-CONNECTOR |
| | 288-7324 | [1] | SEAL-CONNECTOR | |
| | 174-3016 | [1] | PLUG AS-CONNECTOR(3-PIN) | |
| | 8T-8737 | [10] | PLUG-SEAL | |
| | 176-9299 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (EACH INCLUDES RECEPTACLE AS & WEDGES) |
| | 272-2840 | [1] | RECEPTACLE AS-CONNECTOR(31-PIN) | |
| | 359-5180 | [1] | RECEPTACLE AS(14-PIN) | |
| | 143-5122 | [2] | RESISTOR AS | |
| | | | (EACH INCLUDES) |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 5P-5677BD | | WIRE(18-GA, BLACK) | |
| | 8T-8729 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 311-2813 | [1] | SEAL | |
| | 194-5226 | [16] | WIRE AS(16-GA) | |
| | | | -OR- |
| | 194-5227 | [16] | WIRE AS(14-GA) | |
| | 9X-3402 | [113] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 3S-2093 | [2] | STRAP-CABLE | |
| | 7K-1181 | [2] | STRAP-CABLE | |
| | 1P-0810B | | TAPE-ELECTRICAL | |
| | 329-3734B | | TAPE-ELECTRICAL | |
| | 5P-4571 | [2] | TERMINAL-BLADE(14-GA TO 16-GA) | |
| | 097-7234 | [2] | TERMINAL-BLADE(18-GA TO 22-GA) | |
| | 9G-9435 | [6] | TERMINAL-RING(18-GA TO 22-GA, 3/8-IN SCREW) | |
| | 104-1995 | [3] | TERMINAL-BLADE(14-GA TO 18-GA) | |
| | 6V-9023E | | TUBE-HEAT SHRINK(12.7-MM DIA)(4-CM) | |
| | 6V-2689D | | TUBE-HEAT SHRINK(6.35-MM DIA)(0.3-M) | |
| | 125-7874E | | TUBE-HEAT SHRINK(5.72-MM DIA)(105-CM) | |
| | 125-7875E | | TUBE-HEAT SHRINK(7.44-MM DIA)(5-CM) | |
| | 270-2679 | [1] | LOCKWASHER | |
| | 310-0674 | [1] | LOCKWASHER | |
| | 155-2258 | [1] | WEDGE-PLUG LOCK(12-PIN) | |
| | 155-2259 | [1] | WEDGE-PLUG LOCK(8-PIN) | |
| | 155-2260 | [1] | KIT-CONNECTING PLUG(3-PIN) | |
| | | | (INCLUDES PLUG AS, WEDGES, & INTERFACE SEAL) |
| | B | | USE AS REQUIRED |
| | D | | ORDER BY THE METER |
| | E | | ORDER BY THE CENTIMETER |
