凯斯零件查询(428) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/88) (A-57) - POWER TAKE-OFF DRIVE SHAFTS, TWO KNUCKLE, WEASLER, 428 AND 435 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
320 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
674380R2
|
[1] |
STABILIZER
|
IH
wire container
|
| . . |
17452R1
|
[3] |
BOLT,Hex, 1/2"-13 x 1 1/4", G2
|
IH
1/2 x 1-1/4 znd hex-hd mach Superseded by part number: 180175
|
| . . |
120378
|
[3] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
120384
|
[3] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
178373R1
|
[2] |
WASHER
|
IH
17/32 x 1 x 16 ga C-Z Superseded by part number: 495-51053
|
| 2. |
667845R93
|
[1] |
CONTAINER
|
IH
ASSY, four coil wire
|
| 3. |
11833PB
|
[1] |
GUIDE
|
IH
wire Superseded by part number: 1344948C1
|
| 4. |
11792P
|
[1] |
HOLDER
|
IH
BRACKET, wire guide
|
| . . |
18654R1
|
[2] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 2
|
IH
1/4 x 3/4 znd hex-hd mach Superseded by part number: 424-412
|
| . . |
120375
|
[2] |
NUT,Hex, 1/4" - 20, Gr 5
|
IH
Superseded by part number: 7770
|
| . . |
492-11025
|
[2] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
