纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.28[001]) - TANK New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
836 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10273111. | 10273111 | [1] | PLUG,M18 x 1.5 x 13 | BAS Superseded by part number: 16993311 |
| 10516871. | 10516871 | [10] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 10517071. | 10517071 | [6] | LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk | HFILOCKWASHER Superseded by part number: 10517073 |
| 10520360. | 10520360 | [1] | WASHER | MKT Superseded by part number: 10520304 |
| 11106031. | 11106031 | [10] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9 | LECBOLT, Hex, M10 x 20, 10.9, Full Thd |
| 11112131. | 11112131 | [6] | SCREW,Hex, M12 x 20mm, Cl 10.9, Full Thd | LEC Superseded by part number: 43258 |
| 14465180. | 14465180 | [1] | O-RING,72.62mm ID x 3.53mm Width | BHBSEAL Superseded by part number: 14465181 |
| 14467380. | 14467380 | [1] | O-RING,0.139" Thk x 5.609" ID, -255, Cl 5, 75 Duro | LECSEAL |
| 14469280. | 14469280 | [1] | GASKET,0.139" Thk x 9.984" ID, -274, Cl 5, 75 Duro | LECSEAL Superseded by part number: 70924145 |
| 79012574. | 79012574 | [2] | PLUG | LEC |
| 79020384. | 79020384 | [1] | COVER | LEC |
| 79020385. | 79020385 | [1] | COVER | LEC |
| 79020386. | 79020386 | [1] | COVER | LEC |
| 79020387. | 79020387 | [1] | COVER | LEC |
| 14464980. | 14464980 | [1] | O-RING,0.139" Thk x 2.609" ID, -231, Cl 5, 75 Duro | BASSEAL Superseded by part number: 86977781 |
