纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.29[001]) - PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
594 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10571971. | 10571971 | [16] | LOCK WASHER | BHBWASHER Superseded by part number: 412123 |
| 11060476. | 11060476 | [1] | CIRCLIP,M50, Int | MKT |
| 11112821. | 11112821 | [16] | BOLT,Hex, M12 x 40mm, Cl 8.8, Full Thd | HFI Superseded by part number: 86629541 |
| 14456481. | 14456481 | [2] | O-RING,114.02mm ID x 1.78mm Width | LECSEAL |
| 79032706. | 79032706 | [1] | COVER | LEC |
| 79032708. | 79032708 | [2] | BUSHING | LECBUSH |
| 79032709. | 79032709 | [2] | PLATE | LEC |
| 79032711. | 79032711 | [4] | ROLL PIN | LECPIN |
| 79032713. | 79032713 | [2] | SEAL | LEC Superseded by part number: 79032739 |
| 79032715. | 79032715 | [2] | SEAL | LEC Superseded by part number: 79032739 |
| 79032716. | 79032716 | [2] | RING | LEC Superseded by part number: 79032739 |
| 79032717. | 79032739 | [2] | KIT | LECGASKET |
| 79032718. | 79032718 | [2] | RING | LEC Superseded by part number: 79032739 |
| 79032770. | 79032770 | [1] | BODY | LEC |
| 79032771. | 79032771 | [1] | GEAR | LEC |
| 79032772. | 79032772 | [1] | GEAR | LEC |
| 79036824. | 79036824 | [1] | COVER | LEC |
