凯斯零件查询(428) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/88) (A-60[A]) - PLUNGER CRANK SHIELD ATTACHMENT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
913 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
674376R1
|
[1] |
SHIELD
|
IH
ASSY, plunger crank
|
| . . |
18764R1
|
[2] |
HARDWARE,Hex, 5/16"-18 x 3/4", G2
|
IH
BOLT, 5/16 x 3/4 C-Z hex-hd mach Superseded by part number: 424-512
|
| . . |
120376
|
[2] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| . . |
611344R1
|
[2] |
WASHER
|
IH
11/32 x 7/8 x 16 ga C-Z Superseded by part number: 495-61034
|
| 2. |
669184R1
|
[2] |
CLAMP
|
IH
LATCH, PTO shield Superseded by part number: 1333780C1
|
| . . |
436732
|
[4] |
SCREW,Slotted Pan Hd, #10-24 x 1/2"
|
IH
10-24 x 1/2 C-Z slt-pan-hd mach Superseded by part number: 70-1108
|
| . . |
120217
|
[4] |
LOCK WASHER,#10
|
IH
WASHER, LOCK, #10 Superseded by part number: 80684
|
| . . |
3479
|
[4] |
WASHER,7/32" x 9/16" x .060"
|
IH
7/32 x 9/16 x 16 ga Superseded by part number: 95-81060
|
