凯斯零件查询(428) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/88) (A-61) - SHIELDS AND GUARDS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
358 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
210503C1
|
[1] |
GUARD
|
IH
ASSY, needle pitman rod
|
| . . |
18508R1
|
[1] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 znd sq-nk crg Superseded by part number: 86508748
|
| . . |
120377
|
[1] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[1] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 2. |
3103965R2
|
[1] |
SHIELD
|
IH
W/PRODUCT GRAPHICS, needle crank drive
|
| . . |
ZA74950
|
[1] |
PRODUCT GRAPHIC, warning
|
|
| 3. |
673690R1
|
[1] |
BOLT
|
IH
BOLT, 5/16-18 wing
|
| 4. |
210500C1
|
[1] |
BRACKET
|
IH
ASSY, needle drive shield
|
| 5. |
210502C1
|
[1] |
ANGLE
|
IH
needle drive shield
|
| 6. |
210514C1
|
[1] |
SUPPORT
|
IH
ASSY, shield
|
| 7. |
210515C1
|
[1] |
SUPPORT
|
IH
shield top
|
| . . |
18778R1
|
[1] |
SCREW,Hex, 3/8"-16 x 3/4", G2
|
IH
BOLT, 3/8 x 3/4 znd hex-hd mach Superseded by part number: 180120
|
| . . |
482256R1
|
[1] |
BEARING LOCK NUT,Flg, USR, 3/8"-16
|
IH
3/8-16 znd hex lock Superseded by part number: 247780
|
| . . |
16897R1
|
[1] |
CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 5/16 x 3/4 znd sq-nk crg Superseded by part number: 412-512
|
| . . |
938017R1
|
[1] |
FLANGE NUT,Flg, USR, 5/16"-18
|
IH
5/16-18 znd hex lock Superseded by part number: 145458
|
