神钢零件查询(F4HFE613S B004) - ENGINE 5801751515 47538798 821F T4B LECCE (8/13-) (10.101.AB) - CYLINDER HEAD, COVER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
728 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899257 | [1] | HOUSING | TORASSY, Incl 2, 3 |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONHousing, Incl in 1 |
| 3. | 4899245 | [5] | SLEEVE,9mm ID x 13.9mm OD x 55.25mm L | TOR |
| 4. | 2852428 | [6] | WIRE CLAMP,6mm ID | TOR Superseded by part number: 504066132 |
| 5. | 4895432 | [5] | SCREW,M8 x 1.25 x 70mm | TOR |
| 5. | 2852295 | [4] | SCREW,Hex, M8 x 1.25 x 40mm | TORM8 x 1.25 x 40mm Superseded by part number: 16586725 |
| 6. | 4899089 | [2] | SCREW,Hex Flg, M8 x 1.25 x 50 | TOR |
| 7. | 2853788 | [1] | GASKET,10.35mm Thk | TOR Superseded by part number: 504070040 |
| 8. | 4896991 | [6] | BOLT | TOR Superseded by part number: |
| 9. | 2853784 | [1] | GASKET,10.5mm Thk | TOR Superseded by part number: 504070038 |
| 10. | 4893936 | [6] | FLANGE NUT,Hex, M13, RH Thd, Cl 9.8 | TOR |
| 11. | 4899239 | [6] | ISOLATOR,29mm OD x 13mm L | TOR Superseded by part number: 504070041, 504075125 |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 14 |
| 13. | 2853857 | [1] | VALVE COVER | TOR |
| 14. | 4895910 | [1] | VALVE COVER | TORASSY, Incl 12, 13 |
| 15. | NSS | [1] | NOT SOLD SEPARAT | CONCap, Incl in 17 |
| 16. | 2852774 | [1] | GASKET,38mm ID x 51mm OD x 8mm Thk | SM Superseded by part number: 98412146 |
| 17. | 2852773 | [1] | CAP | TORASSY, Incl 15, 16 Superseded by part number: 504262827 |
