| 1. | 241-8368Y | [1] | SWITCH GP-MAGNETIC(24-VOLT)(MAIN POWER) | |
| 2. | 255-2752Y | [1] | SWITCH GP-START(IGNITION)(KEY) | |
| 3. | 487-0447 | [1] | GASKET | |
| 4. | 3E-6328Y | [1] | ALARM GP(24-VOLT) | |
| 5. | 4B-4277 | [2] | WASHER(8.8X17.5X1.6-MM THK) | |
| 6. | 6T-7695 | [2] | SPEAKER AS-RADIO | |
| 7. | 8D-6946 | [1] | FLASHER AS(24-VOLT) | |
| 8. | 8T-9655 | [16] | MOUNT-ISOLATION | |
| 9. | 9D-4068 | [1] | SWITCH AS-PUSH BUTTON(HOOD) | |
| 10. | 110-6391 | [1] | CABLE AS-COAXIAL | |
| 11. | 6V-9189M | [8] | LOCKNUT(M8X1.25-THD) | |
| 12. | 114-6658 | [2] | WASHER(6.5X17X1-MM THK) | |
| 13. | 228-6089 | [2] | PLUG(ROCKER SWITCH) | |
| 14. | 536-6607 | [1] | WIRE AS | |
| 15. | 234-5925 | [1] | GASKET | |
| 16. | 257-4907 | [1] | COVER AS-ACCESS | |
| 17. | 311-2813 | [1] | SEAL | |
| 18. | 081-5930 | [1] | CABLE AS-CHASSIS | |
| | 1S-7251 | [2] | TERMINAL-CABLE(00-GA, 1/2-IN SCREW) | |
| 19. | 288-1401 | [2] | BRACKET | |
| 20. | 325-9407 | [1] | FILM-IDENTIFICATION(WRITE DATA) | |
| 21. | 335-5365 | [1] | SOCKET-AUXILIARY POWER(12-VOLT) | |
| 22. | 338-1128 | [1] | LAMP AS-DOME(12/24-VOLT, LED)(LED) | |
| 23. | 340-7161 | [1] | CONVERTER-POWER(24-VOLT TO 12-VOLT) | |
| 24. | 367-9470 | [1] | SWITCH AS-PUSH BUTTON(EMERGENCY STOP) | |
| | 102-8804 | [1] | KIT-RECEPTACLE(4-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 3E-3377 | [1] | WEDGE-RECEPTACLE LOCK(4-PIN) | |
| | 9X-3401 | [4] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| 25. | 381-8082 | [1] | COVER AS | |
| 26. | 419-3911 | [2] | LAMP GP-INDICATOR(12/24-VOLT, AMBER) | |
| | | | (EACH INCLUDES) |
| | 8T-8729 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8802 | [2] | KIT-RECEPTACLE(2-PIN) | |
| | | | (EACH INCLUDES RECEPTACLE AS & WEDGE) |
| 27. | 455-9568 | [1] | CAP AS | |
| | 424-4322 | [1] | COVER-CONNECTOR | |
| 28. | 455-9580 | [2] | CONTROL GP-UNPROGRAMMED(ELECTRONIC) | |
| 29. | 456-8327 | [1] | CABLE AS | |
| 30. | 459-2222 | [1] | MODULE GP-DISPLAY | |
| 31. | 459-2356 | [1] | WIRE AS | |
| 32. | 461-7396 | [1] | PANEL AS | |
| | 271-7312 | [2] | KNOB | |
| 33. | 468-8069 | [1] | SWITCH AS-ROCKER(HOOD LIGHT) | |
| 34. | 468-8074 | [1] | SWITCH AS-ROCKER(PARKING LIGHTS) | |
| 35. | 468-8077 | [1] | SWITCH AS-ROCKER(REAR LIGHTS) | |
| 36. | 468-8079 | [1] | SWITCH AS-ROCKER(ECONOMY MODE) | |
| | | | (EACH SWITCH AS INCLUDES) |
| | 111-7899 | [1] | GASKET | |
| 37. | 480-7193Y | [1] | HARNESS AS-CAB(SUN VISOR) | |
| 38. | 480-7200 | [1] | BRACKET | |
| 39. | 481-8886 | [1] | PLATE AS | |
| 40. | 485-1288 | [1] | FILM-IDENTIFICATION(FUSE, RELAY) | |
| 41. | 485-1290Y | [1] | HARNESS AS-CAB(CHASSIS POWER) | |
| 42. | 485-4687 | [1] | SWITCH AS-ROCKER(AUXILIARY HOIST) | |
| | 111-7899 | [1] | GASKET | |
| 43. | 487-0445 | [1] | PLATE AS | |
| 44. | 495-0342Y | [1] | HARNESS AS-CAB(WINDOW WASHER) | |
| 45. | 495-0343Y | [1] | HARNESS AS-CAB(MAIN) | |
| 46. | 502-6415Y | [1] | HARNESS AS-CAB(UPPER) | |
| 47. | 510-6166 | [1] | SWITCH AS-ROCKER(HAZARD LIGHT) | |
| | 111-7899 | [1] | GASKET | |
| 48. | 352-0244 | [10] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 49. | 8T-4205 | [2] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 50. | 522-1707 | [1] | SWITCH AS-ROCKER(HVAC) | |
| | 111-7899 | [1] | GASKET | |
| 51. | 132-5789 | [1] | CLIP(LADDER) | |
| 52. | 174-8131M | [10] | SCREW-TRUSS HEAD(M4X0.7X12-MM) | |
| 53. | 199-1187M | [2] | NUT(M5X0.8-THD) | |
| 54. | 290-5562 | [3] | MOUNT(DUAL SWIVEL) | |
| 55. | 242-7386 | [4] | WASHER(5.95X9.5X0.95-MM THK) | |
| 56. | 264-3627M | [2] | BOLT(M10X1.5X20-MM) | |
| 57. | 271-9408M | [4] | SCREW-TRUSS HEAD(M5X0.8X10-MM) | |
| 58. | 352-3968 | [2] | CLIP(LADDER) | |
| 59. | 3S-2093 | [56] | STRAP-CABLE | |
| 60. | 4P-7581 | [2] | CLIP(LADDER) | |
| 61. | 5P-8525 | [1] | GROMMET | |
| 62. | 6D-3479 | [2] | CLIP(LOOP) | |
| 63. | 6I-1418 | [8] | SPACER(8.2X12.7X28.7-MM THK) | |
| 64. | 6V-7357M | [2] | BOLT(M6X1X25-MM) | |
| 65. | 6V-8225M | [2] | NUT(M6X1-THD) | |
| 66. | 7I-2272M | [4] | BOLT(M5X0.8X12-MM) | |
| 67. | 7K-1181 | [83] | STRAP-CABLE | |
| 68. | 8K-1433 | [1] | GROMMET | |
| 69. | 8M-2770 | [2] | CLIP(LOOP) | |
| 70. | 8T-0328 | [2] | WASHER-HARD(5.5X10X1-MM THK) | |
| 71. | 8T-4121 | [13] | WASHER-HARD(11X21X2.5-MM THK) | |
| 72. | 8T-4137M | [11] | BOLT(M10X1.5X20-MM) | |
| 73. | 8T-4138M | [8] | BOLT(M6X1X20-MM) | |
| 74. | 8T-4189M | [2] | BOLT(M8X1.25X20-MM) | |
| 75. | 8T-4224 | [2] | WASHER-HARD(8.8X16X2-MM THK) | |
| 76. | 9G-2673 | [1] | GROMMET | |
| 77. | 9X-2042M | [16] | SCREW-TRUSS HEAD(M6X1X12-MM) | |
| 78. | 9X-2043M | [2] | SCREW-TRUSS HEAD(M6X1X14-MM) | |
| 79. | 9X-2045M | [6] | SCREW-TRUSS HEAD(M6X1X20-MM) | |
| 80. | 9X-8256 | [10] | WASHER(6.6X12X2-MM THK) | |
| 81. | 111-4627M | [1] | SCREW-MACHINE(M6X1X30-MM) | |
| | M | | METRIC PART |
| | R | | REMANUFACTURED PART MAY BE AVAILABLE |
| | Y | | SEPARATE ILLUSTRATION |
