纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.32/B[001]) - CYLINDER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
698 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8280834. | 8280834 | [1] | DOWEL | LEC |
| 8281061. | 8281061 | [1] | GASKET | LECSEAL |
| 8284307. | 8284307 | [1] | GASKET | LECSEAL Superseded by part number: 45025031 |
| 8287882. | 8287882 | [4] | SCREW | LEC |
| 8288733. | 8288733 | [1] | SEAL,69.96mm ID x 78.6mm OD x 9mm Thk | LECMUDSCRAPER RING |
| 8288734. | 8288734 | [2] | RING | MKTBUSHING Superseded by part number: 45026114 |
| 8292259. | 8292259 | [1] | NUT | LEC |
| 8292365. | 8292365 | [1] | BASE PLATE | LECEND PLATE |
| 8293425. | 8293425 | [2] | HYDRAULIC VALVE | LECVALVE |
| 8293426. | 8293426 | [1] | SPRING | LEC |
| 8294846. | 8294846 | [1] | BARREL | LEC |
| 8294850. | 8294850 | [1] | ROD | LEC |
| 8294851. | 8294851 | [2] | PISTON | LECHALF-PISTON |
| 8294852. | 8294852 | [1] | WASHER | LEC |
| 8298198. | 8298198 | [1] | SPACER | LEC |
| 8298265. | 8298265 | [1] | RING | LECRETAINER |
| 11062476. | 11062476 | [1] | SNAP RING,M90, Int | TTFRING, LOCKING, M90, Int Superseded by part number: |
| 14467080. | 14467080 | [1] | O-RING,0.139" Thk x 5.234" ID, -252, Cl 5, 75 Duro | LEC-252, 70 Duro, 5.234" ID x .139" Thk Superseded by part number: 79051081 |
