| 1. |
674431R1
|
[1] |
RIM
|
IH
ASSY, left wheel, for 760 x 15 tire, for 440 Baler Superseded by part number: T40663
|
| 1. |
674114R1
|
[1] |
|
P
RIM ASSY LEFT WHEEL, for 430 Baler, for 640 x 15 tire
|
| 2. |
519467R91
|
[1] |
BEARING ASSY,0.8125" ID x 1.939" OD x 0.848"
|
IH
ASSY, left wheel outer cone, for 430 Baler Superseded by part number: 86613102
|
| 2. |
651818R91
|
[1] |
ROLLER BEARING,31.77 mm ID x 16.08 mm
|
IH
BEARING ASSY, left wheel outer cone, for 440 Baler Superseded by part number: 84356153
|
| 3. |
M32951
|
[1] |
BEARING CUP,0.75" ID x 1.938" OD x 0.78125"
|
IH
BEARING, left wheel outer cup, for 430 Balers Superseded by part number: 86539200
|
| 3. |
651817R1
|
[1] |
BEARING CUP
|
IH
BEARING, left wheel outer cup, for 440 Baler Superseded by part number: 84356153
|
| 4. |
662993R11
|
[1] |
HUB
|
IH
ASSY, wheel LH, for 430 Balers
|
| 4. |
465497R11
|
[1] |
|
P
HUB W/BEARING CUPS, left wheel, for 440 Baler
|
| 5. |
ST991
|
[1] |
BEARING CUP
|
IH
BEARING, left wheel inner cup, for 430 Balers Superseded by part number: 116210
|
| 5. |
663558R1
|
[1] |
BEARING CUP
|
IH
BEARING, left wheel inner cup, for 440 Baler Superseded by part number: 86512015
|
| 6. |
453279R91
|
[1] |
ROLLER BEARING,1.375" ID x 2.717" OD x 1.0625"
|
IH
ASSY, left wheel inner cone, for 430 Baler Superseded by part number: 36737
|
| 6. |
663557R91
|
[1] |
BEARING ASSY,1.625" ID x 2.892" OD x 0.77"
|
IH
BEARING ASSY, left wheel inner cone, for 440 Baler Superseded by part number: 86512015
|
| 7. |
661876R91
|
[1] |
OIL SEAL
|
IH
SEAL, left wheel brg, for 430 Baler Superseded by part number: 661875R91
|
| 7. |
654674R91
|
[1] |
OIL SEAL
|
IH
left wheel grease, for 440 Baler
|
| 8. |
674112R1
|
[1] |
AXLE
|
CAS
SPINDLE, wheel LH, for 430 Baler
|
| . . |
180188
|
[2] |
BOLT,Hex, 1/2" - 13 x 2 3/4", Gr 5
|
IH
SCREW, 1/2-13 x 2-3/4 C-Z hex-hd cap Superseded by part number: 113-426
|
| . . |
120378
|
[2] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
120384
|
[2] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
427640
|
[1] |
SLOTTED NUT,3/4"-16, G5
|
IH
NUT, 3/4-16 C-Z slt hex. Superseded by part number: 129-290
|
| . . |
467750R1
|
[1] |
WASHER
|
IH
25/32 x 1-1/2 x 11 ga C-Z Superseded by part number: 87034831
|
| . . |
137218
|
[1] |
COTTER PIN,5/32" x 1 1/4"
|
IH
PIN, SPLIT (COTTER), 5/32" x 1 1/4" Superseded by part number: 86523851
|
| 8. |
674113R1
|
[1] |
SPINDLE
|
IH
wheel LH, for 440 Balers
|
| . . |
180191
|
[2] |
BOLT,Hex, 1/2" - 13 x 3 1/4", Gr 5
|
IH
SCREW, 1/2-13 x 3-1/4 hex-hd cap Superseded by part number: 113-427
|
| . . |
70120D
|
[1] |
SLOTTED NUT,7/8"-14
|
IH
NUT, 7/8-14 slt hex. jam
|
| . . |
21715R1
|
[1] |
WASHER
|
IH
29/32 x 1-3/4 x 11 ga C-Z Superseded by part number: 495-81060
|
| . . |
87395
|
[1] |
COTTER PIN,1/8" OD x 1-1/4" OAL
|
NH
PIN, SPLIT (COTTER), 1/8" x 1-1/4"
|
| 9. |
662994R91
|
[1] |
WHEEL
|
IH
RIM ASSY, right wheel, for 500 x 15 tire
|
| 10. |
351079R1
|
[10] |
BOLT,Hex Counter Shank, 1/2" - 20 x 23/32"
|
IH
wheel Superseded by part number: 32383
|
| 11. |
651194R1
|
[1] |
CAP
|
IH
hub, 2 for 430 Balers, 1 for 440 Balers
|
| 11. |
663906R1
|
[1] |
CAP
|
IH
left wheel hub, for 440 Baler Superseded by part number: 249128
|
| 12. |
651815R91
|
[1] |
BEARING ASSY,7.508" ID x 17.82" OD x 6"
|
IH
BEARING ASSY, right wheel outer cone Superseded by part number: 179080
|
| 12. |
651815R91GV
|
[1] |
BEARING CONE
|
MKT
Value, Cone Bearing
|
| 13. |
651814R1
|
[1] |
BEARING CUP
|
IH
BEARING, right wheel outer cup Superseded by part number: 36725
|
| 14. |
663054R91
|
[1] |
HUB
|
IH
ASSY, wheel RH
|
| 17. |
663004R91
|
[1] |
OIL SEAL
|
IH
right wheel brg Superseded by part number: B13281
|
| 18. |
662981R1
|
[1] |
SPINDLE
|
IH
wheel RH
|
| . . |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
5/8-18 C-Z slt hex.
|
| . . |
131016
|
[1] |
WASHER
|
IH
21/32 x 1-5/16 x .095 C-Z Superseded by part number: 396-21066, 396-21066, NLS
|
| . . |
120169
|
[1] |
COTTER PIN,5/32" x 1"
|
IH
PIN, SPLIT (COTTER), 5/32" x 1" Superseded by part number: 83903970
|
| 19. |
654675R1
|
[1] |
RING
|
IH
left wheel oil seal wear, for 440 Baler
|
