纽荷兰零件查询(FD255) - CRAWLER DOZER (N.A. VERSION) (7/95-) (0.500[2A]) - PIPING - FUEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
593 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 11106431 | [2] | SCREW,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LEC, Start Serial: D3747 Superseded by part number: 9515003 |
| 2. | 12626231 | [2] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC, Start Serial: D3747 |
| 3. | 4982514 | [5] | CABLE TIE | LEC, Start Serial: D3747 Superseded by part number: 87615202 |
| 4. | 4783070 | [1] | BANJO FITTING | LEC, Start Serial: D3747 Superseded by part number: 98417523 |
| 5. | 79035959 | [2] | SEAL | LEC, Start Serial: D3747 Superseded by part number: 44906168 |
| 6. | 10184317 | [1] | BANJO BOLT,M14 x 1.5 x 27mm | BHB, Start Serial: D3747 Superseded by part number: 10184311 |
| 7. | 79083842 | [2] | HOSE CLAMP,M16-27 | LEC, Start Serial: D3747 Superseded by part number: 18088392 |
| 8. | LEC1940141 | [1] | ENGINE TOP GASKETS KIT | LEC |
| 8. | 1940142 | [1] | ENGINE GASKET KIT | LEC |
