现代零件查询R210/220LC-7H AIR CONDITIONER MOUNTING(#1277-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
814 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
11N6-91040
|
[1] |
COMPRSSOR ASSY
|
|
| 2. |
11EM-90050
|
[1] |
CONDENSER ASSY
|
|
| 3. |
11N6-90060
|
[1] |
DRIER-RECEIVER
|
|
| 4. |
11N6-91110
|
[1] |
DIS HOSE ASSY
|
|
| 4. |
11N6-96040
|
[1] |
DISCHARGE HOSE
|
|
| 4-1. |
A305000205-2
|
[1] |
O-RING
|
|
| 5. |
11N6-90080
|
[1] |
HOSE-LIQUID/A
|
|
| 5-1. |
A305000209-2
|
[2] |
O-RING
|
|
| 6. |
11NB-90051
|
[1] |
V-BELT
|
|
| 7. |
11N6-96030
|
[1] |
BRACKET-COMP.
|
|
| 8. |
11N6-90340
|
[1] |
FILTER-REC
|
|
| 11. |
S109-080856
|
[4] |
BOLT-SOCKET
|
|
| 12. |
S403-08200B
|
[4] |
WASHER-PLAIN
|
|
| 13. |
S411-080006
|
[4] |
WASHER-SPRING
|
|
| 14. |
S035-082526
|
[4] |
BOLT-W/WASHER
|
|
| 15. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 16. |
S543-400002
|
[1] |
CLAMP-TUBE
|
|
| 17. |
S037-102026
|
[1] |
BOLT-W/WASHER
|
|
| 18. |
S205-06100B
|
[2] |
NUT-HEX
|
|
| 19. |
S403-06200B
|
[2] |
WASHER-PLAIN
|
|
| 20. |
S411-080006
|
[2] |
WASHER-SPRING
|
|
| 21. |
S037-104556
|
[4] |
BOLT-W/WASHER
|
|
| 22. |
S091-060156
|
[3] |
BOLT-WING
|
|
| 23. |
S403-06200B
|
[3] |
WASHER-PLAIN
|
|
| 28. |
11N6-90120
|
[1] |
BRACKET-R/DRIER
|
|
| 29. |
S038-103556
|
[1] |
BOLT-W/WASHER
|
|
| 30. |
11N6-90110
|
[1] |
PULLEY-IDLE
|
|
| 31. |
S037-102026
|
[3] |
BOLT-W/WASHER
|
|
