纽荷兰零件查询(E135SR) - CRAWLER EXCAVATOR ASN YY04-06254 (01-002[01]) - COUNTERWEIGHT ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
352 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YY60C00015P1 | [1] | COUNTERWEIGHT | KOB |
| . . | YY60C00016F1 | [1] | COUNTERWEIGHT | KOBINSTAL (STD) |
| B1. | HS13C27155G1 | [4] | CAPSCREW | KOBSCREW CAP |
| B2. | HY26Y28060G2 | [4] | WASHER,28mm ID x 60mm OD x 12mm Thk | KOB |
| B3. | 2420Z1340D2 | [2] | PLUG | KOB |
| B4. | YT60C01007P1 | [3] | PLUG | KOB |
| . . | YY60C00007F9 | [1] | COUNTERWEIGHT INSTAL (NHK.GAIN) | |
| C1. | YY60C00006P1 | [1] | COUNTERWEIGHT | KOB |
| C4. | LE60C01028P1 | [2] | PLATE | KOB |
| C8. | HS18C20135G1 | [3] | BOLT | KOBCAP |
| C9. | HY26Y21050G4 | [3] | WASHER | KOB |
| C13. | LC22T00069P1 | [1] | NAMEPLATE | KOBNAME PLATE |
| . . | YY60C00041F2 | [1] | COUNTERWEIGHT GROUP | |
| D1. | YY60C01034P1 | [1] | INSULATING PANEL | KOB |
| D2. | YY60C01040P1 | [1] | INSULATING PANEL | KOB |
| D3. | YY60C01042P1 | [1] | INSULATING PANEL | KOB |
| D4. | YY60C01043P1 | [1] | INSULATING PANEL | KOB |
