神钢零件查询(F4HFE613T A004) - ENGINE 504384900 - 84232924 (3/11-) (10.218.01[01]) - FUEL LINES & RELATED PARTS (2857045) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
849 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2859144 | [1] | MANIFOLD | BHBASSY Superseded by part number: |
| 2. | 2853537 | [4] | BOLT,Hex Flange Head Cap M8 x 1.25 x 125mm | TOR Superseded by part number: 504053874 |
| 3. | 4899020 | [1] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16673635 |
| 4. | 2854543 | [1] | VALVE PRESSURE RELIE | TOR |
| 5. | 2859145 | [1] | SENSOR | TOR Superseded by part number: |
| 6. | 2857048 | [1] | PIPE | TOR Superseded by part number: |
| 7. | 2857046 | [3] | PIPE | TOR Superseded by part number: |
| 8. | 2857017 | [3] | PIPE | TOR Superseded by part number: |
| 9. | 4896884 | [1] | BOLT,Flng, M8 x 1.25 x 16mm, Cl 10.9 | TOR |
| 10. | 17816011 | [1] | SPACER | TOR Superseded by part number: 13605711 |
