神钢零件查询(F4HFE613T A004) - ENGINE 504384900 - 84232924 (3/11-) (10.402.01 01) - PIPING - ENGINE COOLING SYSTEM (2856257 - 2855824 - 2855442) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
245 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852286 | [2] | BOLT,Flng, M10 x 1.5 x 130mm | TOR Superseded by part number: 16599125 |
| 2. | 2854424 | [1] | SCREW,Hex, Flg Hd, M10 x 1.5 x 70mm | TOR Superseded by part number: 16676834 |
| 3. | 4893036 | [1] | PIPE PLUG,3/4"-14 NPTF | TOR Superseded by part number: 2854866 |
| 4. | 4895080 | [1] | HEX SOCKET PLUG,M22 x 1.5 | TOR |
| 6. | 2854072 | [1] | SEALING RING,Square, 5.16mm Thk x 50.17mm ID | TOR Superseded by part number: 504062710 |
| 7. | 2854072 | [1] | SEALING RING,Square, 5.16mm Thk x 50.17mm ID | TOR Superseded by part number: 504062710 |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 10. | 98405182 | [2] | DOWEL | TOR |
| 11. | 4895623 | [1] | HEX SOCKET PLUG,M16 x 1.5 | TOR |
| 13. | 4895625 | [1] | O-RING,13.3mm ID x 2.2mm Width | TOR Superseded by part number: 17281681 |
| 14. | 4895392 | [1] | HEX SOCKET PLUG,M18 x 1.5 | TOR |
