凯斯零件查询(440) - INTERNATIONAL HARVESTER CUSTOM RECTANGULAR BALER (1/70-12/78) (F-43[A]) - SMV EMBLEM AND LIGHT BRACKET SOCKET Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
285 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
202169C1
|
[1] |
BRACKET
|
IH
SMV emblem
|
| 2. |
363919R1
|
[1] |
SOCKET
|
IH
light bracket Superseded by part number: 398976R1
|
| . . |
20485R1
|
[1] |
BOLT,Short NK, 7/16"-14 x 3/4", G5. Full Thd
|
IH
7/16 x 3/4 C-Z sq-nk crg
|
| . . |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
NUT, 7/16-14 C-Z hex.
|
| . . |
120383
|
[1] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
