神钢零件查询(F4HFE613T A004) - ENGINE 504384900 - 84232924 (3/11-) (10.408.01) - HEAT EXCHANGER - ENGINE- ENGINE OIL FILTER (2853603 - 2852525) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
569 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899019 | [10] | SCREW,Hex Flg, M8 x 1.25 x 35 | TOR |
| 2. | 4899566 | [1] | FILTER HEAD | TOROil Filter Support |
| 3. | 504096409 | [1] | PLUG | TORComes With O-Ring Superseded by part number: 2853781 |
| 4. | 4896404 | [1] | PLUNGER,10mm ID, 12mm OD, 15.44mm ID, 18.26mm OD | TOR |
| 5. | 4895045 | [1] | SPRING,Compression, 14.7mm OD x 66mm L | TOR |
| 7. | J936365 | [1] | VALVE PRESSURE RELIE | CAS Superseded by part number: 4896410 |
| 8. | 2830559 | [1] | GASKET,0.5mm Thk | TOR |
| 9. | 504387924 | [1] | HEAT EXCHANGER | CUROil Cooler Superseded by part number: |
| 10. | 4893391 | [1] | ADAPTER,M24 x 2 x M27 x 2 | TOR |
| 11. | 84228488 | [1] | ENGINE OIL FILTER,95mm OD x 171mm L, M27x2-6H | BAS |
