674973R91
|
[1] |
PUMP
|
IH
hyd bale density control
|
| . . |
9635884
|
[4] |
BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5
|
NH
5/16-18 x 1 C-Z hex-hd cap
|
| . . |
120376
|
[4] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
80681
|
[4] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 1. |
668390R1
|
[1] |
|
P
KEY, 1/8 x 3/4 sq parallel
|
| 2. |
202996C91
|
[1] |
SEAL
|
IH
shaft oil
|
| 3. |
668382R91
|
[1] |
LARGE PLATE
|
IH
PLATE ASSY, front Superseded by part number: H646265
|
| . . |
180046
|
[4] |
SPRING
|
NNA
SCREW, 1/4-20 x 2-1/4 znd hex-hd cap Superseded by part number: 413-436, 413-436, NLS
|
| 4. |
16006R1
|
[2] |
BALL
|
IH
3/16 cr-stl Superseded by part number: 17006R1
|
| 5. |
668391R1
|
[2] |
SPRING
|
IH
check Superseded by part number: H138420
|
| 6. |
668386R1
|
[1] |
SEAL
|
IH
diaphragm Superseded by part number: H138388
|
| 7. |
668383R1
|
[1] |
GASKET
|
IH
protector Superseded by part number: H138396
|
| 7. |
668384R1
|
[1] |
GASKET
|
IH
backup Superseded by part number: H138404
|
| 8. |
204287C1
|
[1] |
DIAPHRAGM
|
IH
|
| 9. |
668388R91
|
[1] |
GEAR
|
CAS
ASSY, drive
|
| 10. |
668389R91
|
[1] |
GEAR
|
IH
ASSY, idler
|
| 11. |
587594R1
|
[1] |
O-RING
|
IH
1-1/2 x 1 x 1-11/16 x 3/32 Superseded by part number: 375269R1
|
| 12. |
668399R1
|
[1] |
GASKET
|
CAS
reservoir
|
| 13. |
668398R91
|
[1] |
FILTER
|
IH
ASSY
|
| 14. |
668392R91
|
[1] |
|
P
RESERVOIR ASSY, oil
|
| . . |
86627130
|
[1] |
WING NUT,1/4"-20
|
NH
NUT, 1/4-20 znd wing
|
| . . |
180075
|
[3] |
BOLT,Hex, 5/16" - 18 x 5/8", Gr 5
|
IH
SCREW, 5/16-18 x 5/8 znd hex-hd cap Superseded by part number: 9627874
|
| 15. |
668401R1
|
[1] |
SPRING
|
IH
filter pocket
|
| 16. |
668395R11
|
[1] |
FILTER
|
CAS
POCKET W/GASKET, filter
|
| 17. |
668396R1
|
[1] |
CAP
|
CAS
filter
|
| 18. |
668394R1
|
[1] |
CAP
|
CAS
breather
|
| 19. |
668400R1
|
[1] |
FILTER
|
CAS
air
|
| 20. |
668393R11
|
[1] |
COVER
|
CAS
LID W/GASKET, reservoir
|
| 21. |
668402R1
|
[1] |
|
P
GASKET, filter pocket
|
| 22. |
668397R1
|
[1] |
GASKET
|
IH
lid
|
| 24. |
668377R91
|
[1] |
VALVE
|
IH
POPPET ASSY Superseded by part number: H83931
|
| 25. |
203059C1
|
[1] |
SPRING
|
IH
cylindrical compression Superseded by part number: 8040495
|
| 26. |
252707R1
|
[1] |
O-RING,0.103" Thk x 0.75" ID, -116, Cl 5, 75 Duro
|
IH
3/4 x 15/16 x 3/32 Superseded by part number: 86977728
|
| 27. |
120613
|
[1] |
JAM NUT,Hex, 1/4" - 28, Gr 5
|
IH
Superseded by part number: 86976064
|
| 28. |
371544R1
|
[1] |
O-RING,0.07" Thk x 0.551" ID, -15, Cl 5, 75 Duro
|
IH
9/16 x 11/16 x 1/16 class 5, replaces 668830R1 Superseded by part number: 14453280
|
| 30. |
200418C1
|
[1] |
ADJUSTMENT SCREW
|
IH
adj Superseded by part number: 8040560
|
| 31. |
394655R1
|
[2] |
WASHER
|
IH
SHIM, relief valve (as required) Superseded by part number: 64759
|
| 32. |
668403R1
|
[2] |
WASHER
|
IH
WASHER, 17/64 x 31/64 x .050 Superseded by part number: 64759
|
| 33. |
444660
|
[1] |
DRAIN PLUG,Sq Soc, 3/8"-18 NPTF
|
IH
PLUG, 3/8-18 automotive soc-hd pipe
|
| 34. |
200421C1
|
[1] |
PLUG
|
CAS
ASSY, hex.
|
| 35. |
443767
|
[2] |
AXLE PIN
|
IH
PIN, 1/4 x 1/2 dowel
|
| 36. |
352219R1
|
[2] |
O-RING,0.07" Thk x 0.239" ID, -10, Cl 5, 75 Duro
|
IH
1/4 x 3/8 x 1/16 Superseded by part number: 49886
|
| . . |
674974R91
|
[1] |
KIT
|
IH
housing repair, consists of ref 24, 25, 26, 27, 28, 30, 31, 35 and 38
|
| . . |
200419C91
|
[1] |
KIT
|
IH
special knob repair, consists of 1 roll pin, 1 knob and 1 connecting rod
|
| . . |
200420C91
|
[1] |
SEAL KIT
|
CAS
major seal repair, consists of ref 2, 4, 5, 6, 7, 8, 11, 12, 19, 21, 22, 26, 28, 32 and 36
|
