卡特零件查询（730） 479-8126: TRIM GP-CAB
广数供应链运营团队, 15 02月, 2025，浏览：
466 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 172-8591M | [38] | NUT-CLIP(M6X1-THD) | |
| 2. | 206-1667 | [7] | CLIP(TRIM) | |
| 3. | 253-2417 | [2] | LOUVER AS | |
| 4. | 224-4905 | [6] | BUMPER | |
| 5. | 344-2597 | [1] | GASKET | |
| 6. | 419-8564 | [3] | STRAP | |
| 7. | 447-0891 | [3] | LINER(CUP HOLDER) | |
| 8. | 460-4734 | [4] | LOUVER AS | |
| 9. | 460-4738 | [6] | LOUVER AS | |
| 10. | 460-4735 | [2] | LOUVER AS | |
| 11. | 480-4180 | [1] | COVER AS-DASH | |
| 12. | 480-4181 | [1] | COVER AS-DASH | |
| 13. | 480-4182 | [1] | COVER-TRAY | |
| 14. | 480-4183 | [1] | BEZEL(DISPLAY) | |
| 15. | 480-4184 | [1] | BEZEL(CONSOLE) | |
| 16. | 480-4185 | [1] | COVER AS | |
| 17. | 480-4186 | [1] | COVER-STORAGE | |
| 18. | 480-4187 | [1] | COVER(STEERING) | |
| 19. | 481-3257 | [1] | COVER AS | |
| 20. | 488-5314 | [1] | HANDLE AS | |
| 21. | 482-0778 | [1] | COVER-REAR | |
| 22. | 482-0779 | [1] | COVER(WIPER) | |
| 23. | 482-0780 | [1] | COVER(WIPER) | |
| 24. | 482-0781 | [1] | COVER-LOWER | |
| 25. | 482-0782 | [1] | COVER-LOWER | |
| 26. | 482-0783 | [1] | COVER-ACCESS | |
| 27. | 515-9221 | [1] | LINER AS-CAB | |
| 28. | 482-0785 | [1] | BEZEL AS | |
| | 205-7048M | [2] | INSERT-THREADED(M6X1-X14.73-MM) | |
| 29. | 506-1002 | [1] | BEZEL(LIGHT) | |
| 30. | 482-3445 | [1] | COVER | |
| 31. | 482-7528 | [1] | FLOOR MAT | |
| 32. | 482-7531 | [1] | HOOK-COAT | |
| 33. | 482-8804 | [1] | BEZEL(DISPLAY) | |
| 34. | 485-1360 | [1] | DUCT(DASH) | |
| 35. | 485-1374 | [1] | DUCT AS | |
| 36. | 485-3631 | [1] | BIN-STORAGE | |
| 37. | 462-7969 | [1] | INSULATION | |
| 38. | 486-1394 | [1] | COVER(DISPLAY) | |
| 39. | 487-4945 | [1] | DUCT AS(CONSOLE) | |
| 40. | 487-6453 | [1] | COVER-LOWER | |
| 41. | 515-9220 | [1] | LINER AS-CAB | |
| 42. | 488-0356 | [1] | FLOOR MAT | |
| 43. | 462-7970 | [1] | INSULATION | |
| 44. | 462-7981 | [1] | INSULATION | |
| 45. | 509-8141 | [1] | BRACKET AS | |
| 46. | 552-7253 | [2] | HINGE AS | |
| 47. | 488-8340 | [1] | LINER(STORAGE) | |
| 48. | 488-8341 | [1] | LINER(TRAY) | |
| 49. | 488-8342 | [1] | LINER | |
| 50. | 488-8343 | [1] | LINER(HANDLE) | |
| 51. | 489-4542 | [1] | GASKET | |
| 52. | 489-4543 | [1] | GASKET | |
| 53. | 5P-4116 | [9] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 54. | 489-4545 | [1] | GASKET | |
| 55. | 489-4546 | [1] | GASKET | |
| 56. | 489-4547 | [1] | GASKET | |
| 57. | 489-4576 | [1] | GASKET | |
| 58. | 104-2091 | [12] | SCREW-FLAT HEAD(6-20X0.5-IN) | |
| 59. | 114-6658 | [78] | WASHER(6.5X17X1-MM THK) | |
| 60. | 174-8131M | [8] | SCREW-TRUSS HEAD(M4X0.7X12-MM) | |
| 61. | 089-7960 | [2] | WASHER(5.3X25X1.6-MM THK) | |
| 62. | 7K-3434 | [2] | SCREW-TAPPING(6-20X0.75-IN) | |
| 63. | 7X-0579 | [17] | WASHER-HARD(8.8X25.5X2-MM THK) | |
| 65. | 9X-2045M | [55] | SCREW-TRUSS HEAD(M6X1X20-MM) | |
| 66. | 9X-2046M | [4] | SCREW-TRUSS HEAD(M6X1X35-MM) | |
| 67. | 3E-4313M | [2] | SCREW-BUTTON HEAD(M4X0.7X8-MM) | |
| 68. | 510-7162 | [1] | HAMMER GP(EMERGENCY) | |
| | 209-4212 | [1] | HAMMER GP(CAB WINDOW) | |
| 69. | 518-6141 | [1] | INSULATION-DUCT | |
| 70. | 121-9870M | [1] | SCREW-MACHINE(M6X1X40-MM) | |
| 71. | 3E-8020M | [38] | SCREW-TRUSS HEAD(M6X1X25-MM) | |
| 72. | 536-8790 | [1] | BRACKET | |
| 73. | 111-4627M | [3] | SCREW-MACHINE(M6X1X30-MM) | |
| 74. | 9X-2044M | [4] | SCREW-TRUSS HEAD(M6X1X16-MM) | |
| | M | | METRIC PART |
