| 1. |
203187C1
|
[1] |
HOLDER
|
IH
chain
|
| . . |
18421R1
|
[1] |
CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G5, Full Thd Superseded by part number: 412-716
|
| . . |
21331R1
|
[2] |
WASHER
|
IH
15/32 x 1-1/4 x 16 ga znd Superseded by part number: 106265
|
| . . |
473213R1
|
[1] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 znd hex lock Superseded by part number: 280980
|
| 2. |
203091C1
|
[1] |
CHUTE (DOWNWARD)
|
IH
CHUTE, bale
|
| . . |
18508R1
|
[2] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 znd sq-nk crg Superseded by part number: 86508748
|
| . . |
385525R1
|
[2] |
LOCK NUT,3/8"-16, GB
|
IH
NUT, 3/8-16 cad hex lock Superseded by part number: 87039402
|
| . . |
20803R1
|
[2] |
WASHER
|
IH
13/32 x 1 x 11 ga C-Z Superseded by part number: 87613212
|
| 3. |
669647R1
|
[2] |
CHAIN (AG)
|
IH
CHAIN, bale chute
|
| . . |
598804R1
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1 1/4", Gr 5
|
IH
BOLT, 5/16-18 x 1-1/4 znd sq-nk crg Superseded by part number: 280827
|
| . . |
120376
|
[4] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| . . |
668569R1
|
[2] |
WASHER
|
IH
11/32 x 1-1/2 x 11 ga C-Z Superseded by part number: 87020812
|
| . . |
619855R1
|
[4] |
WASHER
|
IH
11/32 x 3/4 x 16 ga Superseded by part number: 86637953
|
| 3. |
495526R1
|
[1] |
CHAIN (AG)
|
IH
CHAIN, bale chamber ext hold-up
|
| . . |
668986R1
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1 1/4", Gr 5
|
IH
BOLT, 5/16-18 x 1-1/4 znd sq-nk crg Superseded by part number: 280827
|
