凯斯零件查询(440) - INTERNATIONAL HARVESTER CUSTOM RECTANGULAR BALER (1/70-12/78) (F-56[A]) - FLYWHEEL, SHIELD AND SUPPORT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
775 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
208166C1
|
[1] |
SHIELD
|
IH
ASSY, flywheel rear
|
| 2. |
208168C1
|
[1] |
SUPPORT
|
IH
flywheel shield
|
| . . |
9411655
|
[1] |
LOCK NUT,3/8"-16, GB
|
IH
NUT, 3/8-16 znd hex lock Superseded by part number: 88902
|
| 3. |
208169C1
|
[1] |
SUPPORT
|
IH
flywheel upper
|
| . . |
17351R1
|
[1] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 znd sq-nk crg Superseded by part number: 88682
|
| . . |
623084R1
|
[1] |
WING NUT
|
IH
NUT, 3/8-16 cad wing Superseded by part number: 103129
|
| . . |
120388
|
[1] |
|
NNA
.438 x 1 x .064 znd Superseded by part number: 495-21044, 495-21044, NLS
|
| . . |
180147
|
[2] |
SCREW,Hex, 7/16" - 14 x 1 1/4", Gr 5
|
IH
7/16-14 x 1-1/4 znd hex-hd cap Superseded by part number: 9627887
|
| . . |
271501
|
[2] |
SOCKET
|
NNA
NUT, 7/16-14 znd hex
|
| . . |
120383
|
[2] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
21760R1
|
[2] |
WASHER,0.47" ID x 0.88" OD x 0.19" Thk
|
IH
.469 x .875 x .164 znd
|
