神钢零件查询(F4HFE613T A005) - ENGINE 5801366317 - 87746887 (9/10-) (10.101.03) - BREATHER - ENGINE (504225957) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
397 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4897534 | [1] | TUBE | TOR |
| 2. | 4897546 | [1] | RUBBER SLEEVE | TOR Superseded by part number: 2854521 |
| 4. | 4897537 | [1] | SCREW | TOR |
| 5. | 4897536 | [1] | BRACKET | TOR |
| 6. | 16511211 | [2] | BANJO BOLT | TOR Superseded by part number: |
| 7. | 4899926 | [4] | SEALING WASHER,11.8mm ID x 18.0mm OD x 1.5mm Thk | TOR |
| 8. | 4899219 | [1] | TUBE | TORASSY |
| 9. | 2855200 | [1] | O-RING | TOR Superseded by part number: 17288281 |
| 10. | 4899110 | [3] | SCREW,Hex Flg, M6 x 1 x 20 | TOR |
| 12. | 4893234 | [2] | HOSE CLAMP | TOR |
| 13. | 4898439 | [1] | O-RING,20.29mm ID x 2.62mm Width | TOR Superseded by part number: 17282081 |
| 14. | 4898372 | [1] | O-RING,13.11mm ID x 2.62mm Width | TOR |
