神钢零件查询(F4HFE613T A005) - ENGINE 5801366317 - 87746887 (9/10-) (10.254.05) - EXHAUST MANIFOLD (504087959) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
610 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4896651 | [1] | EXHAUST MANIFOLD | TOR Superseded by part number: 99454993, 4897890, 99440117, 504047548, 4897889 |
| 2. | 4896650 | [1] | EXHAUST MANIFOLD | TOR Superseded by part number: 504047548, 4897890, 4897889, 99440117, 99454993 |
| 3. | 2853800 | [6] | MANIFOLD GASKET,1.4mm Thk | TOR |
| 4. | 4895336 | [12] | SPACER | TOR Superseded by part number: 47464712 |
| 5. | 4895219 | [4] | STUD,Hex Flng, M10 x 65mm, Cl 10.9 | TOR |
| 6. | 2852744 | [8] | SCREW,Flng, M10 x 1.5 x 65mm | TOR |
| 7. | 4899085 | [4] | STUD,M10 x 1.5 x 42mm | TOR |
