神钢零件查询(F4HFE613T A005) - ENGINE 5801366317 - 87746887 (9/10-) (10.402.01[01]) - PIPING - ENGINE COOLING SYSTEM (504259533 - 504199747 - 504194618) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
682 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 2854424 | [1] | SCREW,Hex, Flg Hd, M10 x 1.5 x 70mm | TOR Superseded by part number: 16676834 |
| 4. | 2855576 | [1] | | |
| 6. | 2852212 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 25mm | TOR |
| 7. | 2854072 | [1] | SEALING RING,Square, 5.16mm Thk x 50.17mm ID | TOR Superseded by part number: 504062710 |
| 10. | 98405182 | [2] | DOWEL | TOR |
| 11. | 4895623 | [1] | HEX SOCKET PLUG,M16 x 1.5 | TORASSY |
| 13. | 4895625 | [1] | O-RING,13.3mm ID x 2.2mm Width | TOR Superseded by part number: 17281681 |
| 14. | 4895392 | [1] | HEX SOCKET PLUG,M18 x 1.5 | TOR |
| 15. | 4893036 | [1] | PIPE PLUG,3/4"-14 NPTF | TOR Superseded by part number: 2854866 |
| 16. | 4895080 | [1] | HEX SOCKET PLUG,M22 x 1.5 | TORASSY |
| 18. | 2854072 | [1] | SEALING RING,Square, 5.16mm Thk x 50.17mm ID | TOR Superseded by part number: 504062710 |
