| 1. |
674373R1
|
[1] |
CHANNEL
|
IH
ASSY, upper tension
|
| . . |
550796R1
|
[1] |
CARRIAGE BOLT,3/8" - 16 x 1 1/4", Grade 5
|
IH
BOLT, 3/8-16 x 1-1/4 znd sq-nk crg, for twine Balers Superseded by part number: 86508749
|
| . . |
120377
|
[1] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[1] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
634979R1
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/2"
|
IH
BOLT, 3/8-16 x 1-1/2 znd sq-nk crg, for wire Balers Superseded by part number: 280552
|
| 2. |
662385R11
|
[2] |
|
P
SCREW ASSY, tension adj, 1968 and 1969
|
| . . |
589068R1
|
[2] |
WASHER
|
IH
21/32 x 1-1/4 x 11 ga C-Z Superseded by part number: 495-51066
|
| 2. |
667994R11
|
[2] |
|
P
SCREW ASSY, bale chamber tension adj.
|
| 3. |
656934R1
|
[2] |
BUSHING
|
IH
PILOT, tension adj screw
|
| 4. |
657223R1
|
[2] |
PLUG
|
IH
bale chamber tension spring, 430T Balers 015403 and below, 430W Balers 002053 and below, 440T Balers 005434 and below, 440W Balers 003032 and below
|
| 4. |
662028R1
|
[2] |
PLUG
|
IH
spring, 430T Balers 0015404 and up, 430W Balers 002054 and up, 440T Balers 005435 and up, 440W Balers 003033 and up
|
| 5. |
674370R1
|
[1] |
|
P
CHANNEL ASSY, lower tension
|
| . . |
18508R1
|
[2] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 znd sq-nk crg Superseded by part number: 86508748
|
| 6. |
674374R1
|
[1] |
|
P
BRACE, lower tension channel
|
| . . |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 C-Z sq-nk crg Superseded by part number: 88682
|
| . . |
180173
|
[2] |
BOLT,Hex, 1/2" - 13 x 1", Gr 5
|
IH
Superseded by part number: 113-424
|
| . . |
120378
|
[2] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
120384
|
[2] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| 7. |
663382R1
|
[2] |
SPRING
|
IH
bale chamber tension, 430T Balers 015403 and below, 430W Balers 002053 and below, 440T Balers 005434 and below, 440W Balers 003032 and below
|
| 7. |
203186C1
|
[2] |
SPRING
|
IH
tension channel, 430T Balers 015404 and up, 430W Balers 002054 and up, 440T Balers 005435 and up, 440W Balers 003033 and up
|
| 8. |
667993R1
|
[2] |
|
P
SUPPORT, upper tension channel spring
|
| 9. |
667837R1
|
[4] |
|
P
COLLAR, manual tension
|
| 10. |
667838R1
|
[2] |
SPRING
|
IH
manual tension
|
| 11. |
667995R11
|
[2] |
|
P
PLATE ASSY, bale chamber tension adj.
|
| 12. |
668120R2
|
[1] |
|
P
CHANNEL, lower tension
|
| 13. |
668764R1
|
[2] |
|
P
STRAP, tension spring
|
| 14. |
200673C1
|
[2] |
CRANK
|
IH
SCREW, assy, tension adjusting, 1970 and up
|
| 15. |
321935C1
|
[2] |
SNAP RING,#62, Ext
|
IH
Ring, Snap, , bale tension knob, 1970 and up #62, Ext Superseded by part number: 129345
|
| 16. |
201397C1
|
[2] |
KNOB
|
IH
ASSY, bale tension, 1970 and up
|
| 17. |
204133C1
|
[1] |
|
P
INDICATOR W/PRODUCT GRAPHIC, bale tension, use w/663382R1 spring
|
