纽荷兰零件查询(E200SR) - CRAWLER EXCAVATOR BTW YB04-02319 - YB04-02550 (01-049[03]) - CONTROLLER GROUP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
580 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB22E00018F1 | [1] | CONTROLLER ASSY, Serial Range: LA04-01506-LA04-01520 | |
| . . | YB22E00018F4 | [1] | CONTROLLER ASSY, Start Serial: LA04-01521 | |
| A1. | YY22E01019P1 | [1] | BOX | KOB |
| A4. | YT50E00001F1 | [1] | SWITCH | KOBASSY (SWING PARKING RELEASE) Superseded by part number: YN50S00047P1 |
| A5. | YR24S00002P1 | [7] | RELAY | KOB |
| A7. | YT22E01006P1 | [1] | LABEL | KOB(SWING PARKING RELEASE) |
| A8. | ZM61C06012 | [12] | BOLT | KOBSEMS |
| A9. | ZM61C06020 | [2] | BOLT | KOBSEMS |
| A10. | 2427Z1594D006 | [1] | TRIM PANEL | KOB |
| A11. | 2427Z1594D028 | [2] | TRIM PANEL | KOB |
| A12. | 2427Z1594D008 | [2] | PROTECTION STRIP | KOBTRIM Superseded by part number: S16539-17000 |
| A13. | YN50S01003P1 | [1] | SWITCH | KOBASSY (KPSS RELEASE) |
| A14. | ZM61C06030 | [3] | BOLT | KOBSEMS |
| A15. | YV22E01002P1 | [1] | LABEL | KOB |
| A16. | LC22E01001D1 | [1] | RESISTOR,16ohm | KOB |
| A17. | ZM41C04012 | [1] | BOLT | KOBSEMS |
| A18. | YY22E01006P1 | [2] | BRACKET | KOB |
| A19. | YV14E01016P1 | [1] | ELEC CONNECTOR | KOB Superseded by part number: AMP917981-6 |
| A23. | YN25S00001P1 | [1] | TIMER | KOB |
| A24. | ZM61C06016 | [1] | BOLT | KOBSEMS |
| A25. | YB14E00014F1 | [1] | HARNESS | KOBASSY, CAB |
| A25-2. | 2432R233D1 | [1] | CLIP | KOB |
| A25-3. | ZW16X06000 | [1] | WASHER | KOB Superseded by part number: 86588450 |
| A25-4. | YB14E01023P1 | [1] | HARNESS | KOB |
| A25-5. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| A25-7. | YN03E01001D5 | [4] | CLIP | KOB |
| A25-8. | 2427Z1594D003 | [1] | SOFT TRIM | KOB |
| A26. | YB73E00002F3 | [1] | FUSE | KOBASSY |
| A26-1. | YN73E00001S001 | [1] | BASE | KOB |
| A26-2. | YN73E00001S002 | [1] | COVER | KOB |
| A26-4. | 2479R655S8 | [11] | FUSE,10 Amp | KOB(10A) Superseded by part number: 87522597 |
| A26-5. | 2479R655S9 | [10] | FUSE | KOB(20A) |
| A26-7. | YB73E00002S006 | [1] | HARNESS | KOB |
| A26-9. | YY73E01005P1 | [1] | LABEL | KOB |
| A32. | EN24S00008P1 | [1] | RELAY | KOBRELAY |
| A36. | ZM61C06025 | [1] | BOLT | KOBSEMS |
| A39. | LC24S00001P1 | [1] | RELAY | KOB |
| A41. | YB22E00013F4 | [1] | CONTROL | KOBASSY (MECHA-TRO), FOR F4 ONLY |
| B1. | ZM22C10025 | [4] | BOLT | KOBSEMS |
| B2. | YT22E01026P1 | [1] | INDICATOR | KOB |
| B3. | 2432R233D3 | [1] | CLIP | KOB |
