卡特零件查询（730） 375-1058: PAN GP-TRANSMISSION OIL
广数供应链运营团队, 15 02月, 2025，浏览：
422 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8S-9130 | [1] | SCREEN-SUCTION | |
| 2. | 9W-1454 | [1] | COVER | |
| 3. | 183-3398 | [2] | CONNECTOR AS | |
| | | | (EACH INCLUDES) |
| | 6V-5049 | [1] | SEAL-O-RING | |
| | 6V-8636 | [1] | CONNECTOR | |
| | 8L-2779 | [1] | SEAL-O-RING | |
| 4. | 266-4198 | [1] | HOUSING-SCREEN | |
| 5. | 268-0226 | [1] | SEAL | |
| 6. | 276-7342 | [1] | TUBE AS | |
| 7. | 305-8956 | [1] | PAN-OIL | |
| 8. | 309-5132 | [1] | PLUG AS | |
| | 5P-9537 | [1] | PLUG-MAGNETIC | |
| | 238-5082 | [1] | SEAL-O-RING | |
| 9. | 309-5133 | [1] | PLUG AS | |
| | 9S-4181 | [1] | PLUG(1-5/16-12-THD) | |
| | 238-5084 | [1] | SEAL-O-RING | |
| 10. | 6V-3551 | [1] | SEAL-O-RING | |
| 11. | 6V-3822M | [2] | BOLT(M10X1.5X35-MM) | |
| 12. | 6V-5839 | [2] | WASHER(11X21X2.5-MM THK) | |
| 13. | 8C-5230 | [1] | SEAL-O-RING | |
| 14. | 8T-4121 | [24] | WASHER-HARD(11X21X2.5-MM THK) | |
| 15. | 8T-4908M | [3] | BOLT(M8X1.25X25-MM) | |
| 16. | 8T-6466M | [24] | BOLT(M10X1.5X60-MM) | |
| | M | | METRIC PART |
