凯斯零件查询(440) - INTERNATIONAL HARVESTER RECTANGULAR BALER (NORTH AMERICA) (1/70-12/78) (E-73[B]) - FLYWHEEL AND BELT SHIELD, WHEN ORDERED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
133 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
671124R91
|
[1] |
|
P
SHIELD W/PRODUCT GRAPHIC, belt
|
| 2. |
663663R1
|
[2] |
|
P
BRACKET, shield support
|
| . . |
18508R1
|
[2] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 C-Z sq-nk crg Superseded by part number: 86508748
|
| . . |
18494R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8 x 1 C-Z hex-hd mach Superseded by part number: 424-616
|
| . . |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[4] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 3. |
663662R2
|
[1] |
|
P
SHIELD, flywheel
|
| . . |
18778R1
|
[3] |
SCREW,Hex, 3/8"-16 x 3/4", G2
|
IH
BOLT, 3/8 x 3/4 C-Z hex-hd mach Superseded by part number: 180120
|
