纽荷兰零件查询(E200SR) - CRAWLER EXCAVATOR BTW YB04-02319 - YB04-02550 (01-061[01]) - HARNESS ASSY, UPP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
540 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB13E00010F1 | [1] | HARNESS ASSY, UPP | |
| 1. | YB13E01008D1 | [1] | CABLE | KOB |
| 2. | YB13E01004D1 | [1] | CABLE | KOB |
| 3. | YB13E01003D1 | [1] | CABLE | KOB |
| 4. | 2486R87D2 | [1] | CABLE | KOBBATTERY |
| 5. | YB13E01023P5 | [1] | WIRE HARNESS | KOBHARNESS, Start Serial: LA04-01522 |
| 6. | LE13E01006P1 | [1] | HARNESS | KOB |
| 7. | ZN18C08007 | [3] | NUT | KOBM08x1.25mm |
| 8. | ZW26X08000 | [3] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| 9. | 2432R233D1 | [2] | CLIP | KOB |
| 10. | ZM61C06012 | [2] | BOLT | KOBSEMS |
| 11. | PY01P01043D4 | [21] | CABLE TIE,4.80mm W x 251mm L | KOB |
| 12. | YT13E01021P2 | [1] | GROMMET | KOB |
| 13. | YN25M01045P1 | [2] | GROMMET | KOB |
| 14. | YB13E01009P1 | [1] | GROMMET | KOB |
| 15. | YB13E01012P1 | [1] | HARNESS | KOB |
| 16. | YY13E01072P1 | [1] | HARNESS | KOB |
| A1. | YB03Z00006P1 | [1] | SCHEMATIC.ELEC (NOT IN SERVICE) | |
