纽荷兰零件查询(E200SR) - CRAWLER EXCAVATOR BTW YB04-02319 - YB04-02550 (01-062[03]) - HARNESS ASSY, CAB New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
502 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB14E00015F1 | [1] | HARNESS ASSY, CAB | |
| 1. | YB14E01014P2 | [1] | HARNESS | KOB |
| 2. | YB14E01024P1 | [1] | HARNESS | KOB |
| 3. | YY14E01039P1 | [1] | HARNESS | KOB |
| 4. | YN03E01001D5 | [3] | CLIP | KOB |
| 5. | YX14E01004P1 | [1] | GROMMET | KOB |
| 6. | PY01P01043D7 | [1] | CABLE TIE,4.80mm W x 445mm L | KOB, Serial Range: LA04-01506-LA04-01512 |
| 7. | PY01P01043D4 | [4] | CABLE TIE,4.80mm W x 251mm L | KOB |
