纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (07-013) - MOTOR ASSY (SWING) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
678 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 51. | YN22V00014F1 | [2] | VALVE | KOBASSY, RELIEF, SEE FIG. 07-036 |
| 52. | YN20V00004F3 | [1] | VALVE | KOBVALVE ASSY, SWING-REACTIONLESS, SEE FIG. 07-026 |
| 53. | YB30V00014F1 | [1] | BY-PASS VALVE | KOBASSY, SEE FIG. 07-018 |
| 101. | YN15V00002S101 | [1] | SHAFT | KOB |
| 111. | YN15V00002S111 | [1] | BLOCK | KOB |
| 113. | YN15V00002S113 | [1] | BUSHING | KOB |
| 114. | YN15V00002S114 | [1] | SPRING | KOB |
| 116. | YN15V00002S116 | [12] | PUSH ROD | KOB |
| 117. | YN15V00002S117 | [1] | SPACER | KOB |
| 118. | YN15V00002S118 | [2] | SPACER | KOB |
| 121. | NSS | [9] | NOT SERVICED SEPARATELY | CONPISTON |
| 123. | YN15V00002S123 | [1] | PLATE | KOBSET |
| 124. | YN15V00002S124 | [1] | PLATE | KOBSHOE |
| 131. | YN15V00002S131 | [1] | PLATE | KOBVALVE |
| 301. | YN15V00002S301 | [1] | BODY | KOB |
| 305. | YN15V00002S305 | [1] | BODY | KOBSEAL |
| 351. | YN15V00002S351 | [2] | HYDRAULIC VALVE | KOB Superseded by part number: YN15V00025S351 |
| 355. | YN15V00002S355 | [2] | SPRING | KOB |
| 390. | YB15V00003S390 | [1] | PLATE | KOBNAME PLATE |
| 391. | 2437U407S983 | [2] | RIVET | KOBPIN |
| 401. | ZS23C20045 | [4] | CAP,Hex Socket Head, M20 x 45mm | KOBSCREW |
| 437. | ZR26X06000 | [1] | RING | KOBRETAINING |
| 438. | ZR26X05200 | [1] | RING | KOBRETAINING |
| 443. | YN15V00002S011 | [1] | ROLLER BEARING | KOBROLLER |
| 444. | YN15V00002S444 | [1] | ROLLER BEARING | KOB |
| 464. | YW30V00001S157 | [1] | PLUG | KOB |
| 469. | YN15V00002S012 | [2] | PLUG | KOB |
| 472. | 2441U564S735 | [1] | O-RING,3.5mm Thk x 173mm ID, 75 Duro | KOB Superseded by part number: YN15V00025S489 |
| 485. | ZD12P01100 | [1] | O-RING | KOB |
| 488. | ZD12P02800 | [2] | O-RING | KOB |
| 491. | YN15V00002S013 | [1] | GASKET | KOB |
| 702. | YN15V00002S014 | [1] | PISTON | KOBBRAKE |
| 706. | 2441U736S706 | [1] | O-RING | KOB |
| 707. | 2415U188S707 | [1] | O-RING | KOB |
| 712. | YN15V00002S712 | [24] | SPRING | KOB Superseded by part number: YN15V00025S712 |
| 742. | YN15V00002S742 | [3] | CLUTCH PLATE | KOBFRICTION |
| 743. | YN15V00002S743 | [4] | STEP PLATE | KOBSEPARATOR |
| 980. | LQ15V00001S982 | [1] | PLUG | KOB |
| 981. | LQ15V00001S983 | [3] | PLUG | KOB |
| 984. | YN15V00002S984 | [1] | PLUG | KOB |
| 992. | ZE82T08000 | [1] | PLUG | KOB |
| 994. | ZE82T12000 | [1] | PLUG | KOB |
| . . | YN15V00012R100 | [1] | KIT | KOBREPAIR KIT CONSISTS OF Ref. 121(9), 122(9) |
| . . | YN15V00002R200 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 303(1), 451(2) |
| . . | YN15V00002R300 | [1] | REPAIR KIT | KOBCONSISTS OF Ref. 472(1), 485(1), 488(2) 491(1), 706(1), 707(1) |
