凯斯零件查询(445) - INTERNATIONAL HARVESTER RECTANGULAR BALER (NORTH AMERICA) (1/76-12/88) (A-50) - POWER TAKE-OFF DRIVE SHAFT CLUTCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
320 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
662270R1
|
[1] |
PLATE
|
IH
clutch pressure
|
| 2. |
201744C1
|
[2] |
FACING
|
IH
clutch Superseded by part number: 201744C2
|
| 3. |
201743C1
|
[1] |
DISC
|
IH
over running clutch
|
| 4. |
670687R11
|
[1] |
SPACER
|
IH
ASSY, clutch, set of 7
|
| 5. |
662269R1
|
[1] |
PLATE
|
IH
clutch back
|
| 6. |
M1015
|
[7] |
SPRING
|
IH
clutch
|
| . . |
18710R1
|
[7] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 3", Gr 2
|
IH
BOLT, 1/2 x 3 C-Z sq-nk crg Superseded by part number: 80280818
|
| . . |
474848R1
|
[7] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 C-Z hex. lock Superseded by part number: 231-4218
|
| . . |
460908R1
|
[7] |
WASHER
|
IH
17/32 x 1-1/2 x 11 ga C-Z Superseded by part number: 86624147
|
| 7. |
662241R1
|
[2] |
RATCHET
|
IH
DOG, over-running clutch Superseded by part number: 3101008R1
|
| . . |
138086
|
[2] |
CLEVIS PIN,1/2" x 1.360"
|
IH
PIN, 1/2 x 1-27/64 rod end C-Z Superseded by part number: 86636813
|
| 8. |
201742C2
|
[1] |
CARRIER
|
IH
overunning dog
|
| . . |
18795R1
|
[4] |
BOLT,Hex, 7/16"-14 x 1 1/4", G2
|
IH
7/16 x 1-1/4 C-Z hex-hd mach Superseded by part number: 179860
|
| . . |
120383
|
[4] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
