纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (07-037) - REDUCTION ASSY (PROPELLING) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
445 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN53D00008F2 | [1] | REDUCER | KOBASSY (PROPELLING) Superseded by part number: YN53D00008F3 |
| . . | YN53D00008F3 | [1] | HYDRAULIC MOTOR | KOBREDUCTION ASSY (PROPELLING) |
| 1. | YN53D00008S001 | [1] | COVER | KOB |
| 4. | LQ15V00005S004 | [3] | BEARING | KOBNEEDLE |
| 5. | YN53D00008S005 | [6] | WASHER | KOB |
| 6. | YN53D00008S006 | [3] | GEAR | KOBPLANETARY |
| 8. | LQ15V00005S008 | [1] | PLATE | KOBTHRUST |
| 9. | YN53D00008S009 | [1] | GEAR | KOBSUN |
| 10. | YN53D00008S010 | [1] | GEAR | KOBSUN |
| 13. | YN53D00004S013 | [3] | BEARING | KOBNEEDLE |
| 14. | YN53D00008S014 | [3] | GEAR | KOBPLANETARY |
| 15. | ZP26D06036 | [3] | PIN | KOBSPRING, FOR F1 ONLY |
| 16. | YN53D00008S016 | [6] | THRUST WASHER | KOB |
| 17. | YN53D00008S017 | [1] | GEAR | KOBRING |
| 18. | YN53D00008S018 | [1] | HOUSING | KOBFOR F1 & F2 ONLY |
| 19. | YN53D00008S019 | [2] | BEARING | KOB |
| 20. | YN53D00008S020 | [1] | SHIM | KOB |
| 21. | YN53D00008S021 | [2] | WASHER | KOBLOCK |
| 22. | YN53D00004S022 | [1] | RING | KOB |
| 23. | YN53D00008S023 | [1] | SEAL | KOBFLOATING |
| 24. | ZS23C10025 | [15] | SCREW,Hex Socket Head, M10 x 25mm | KOBCAP Superseded by part number: ZS28C10025 |
| 25. | ZS23C16080 | [19] | CAPSCREW,Hex Socket Head, M16 x 80mm | KOBSCREW CAP, FOR F1 & F2 ONLY |
| 26. | ZE82T12000 | [2] | PLUG | KOB |
| 27. | YN53D00008S027 | [1] | ROTOR | KOBFOR F2 & F3 ONLY |
| 28. | YN53D00008S028 | [3] | PIN | KOBFOR F2 & F3 ONLY |
| 29. | ZP26D05032 | [3] | PIN | KOBSPRING, FOR F2 & F3 ONLY |
| 30. | YN53D00008S030 | [1] | ROTOR | KOBFOR F2 & F3 ONLY |
| 31. | YN53D00008S031 | [3] | PIN | KOBSPRING, FOR F2 & F3 ONLY |
| 32. | ZP26D08040 | [3] | PIN | KOBSPRING, FOR F2 & F3 ONLY |
| 34. | ZS23C16090 | [19] | SCREW,Hex Socket Head, M16 x 90mm | KOBCAPSCREW, FOR F3 ONLY |
| . . | YN53D00008R100 | [1] | KIT | KOBREPAIR KIT CONSISTS OF Ref. 4(3), 5(6), 6(3), 27(1), 28(3), 29(3), FOR F2 & F3 ONLY |
| . . | YN53D00008R200 | [1] | REPAIR KIT | KOBREPAIR KIT CONSISTS OF Ref. 13(3), 14(3), 16(6), 30(1), 31(3), 32(3), FOR F2 & F3 ONLY |
