凯斯零件查询(46) - MCCORMICK-INTERNATIONAL PICK UP RECTANGULAR BALER (1/57-12/63) (08) - WARNING LAMP BRACKET AND SOCKET Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
184 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
624341R1
|
[1] |
SOCKET
|
CAS
lamp Superseded by part number: 398976R1
|
| . . |
14994R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2 Superseded by part number: 434-512
|
| . . |
9635082
|
[2] |
NUT,5/16" - 18, Gr 5
|
NH
hex., 5/16-18NC
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
Q397
|
[2] |
WASHER
|
IH
plain, 11/32" ID x 3/4" OD x no. 16 ga. Superseded by part number: 95-81069
|
| 2. |
660510R1
|
[2] |
|
P
BRACKET, warning lamp
|
| . . |
14995R1
|
[2] |
BOLT
|
IH
carriage, 3/8-16NC x 3/4" Superseded by part number: 19284R1
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 3. |
660508R1
|
[6] |
|
P
CLIP, cable
|
| 4. |
660512R91
|
[1] |
|
P
BRACKET AND SOCKET, warning lamp, w/clips
|
| . . |
624342R91
|
[1] |
REFLECTIVE TAPE PACKAGE (Consists of two 2 x 8" strips of Scotchlight tape, or equivalent)
|
|
