现代零件查询R210/220LC-7H ARM HYD PIPING(L/REACH)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
258 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
31N6-66011
|
[1] |
PIPE ASSY
|
|
| 3. |
31N6-66021
|
[1] |
PIPE ASSY
|
|
| 4. |
31N6-66030
|
[1] |
PIPE ASSY-GREASE
|
|
| 4. |
31N6-66031
|
[1] |
PIPE ASSY-GREASE
|
|
| 5. |
31N6-66040
|
[1] |
PIPE ASSY-GREASE
|
|
| 6. |
31N6-66121
|
[2] |
HOSE ASSY
|
|
| 7. |
31N6-66130
|
[2] |
HOSE ASSY
|
|
| 8. |
P600-042012
|
[1] |
HOSE ASSY-THD 0X0
|
|
| 9. |
31EE-51000
|
[10] |
CLAMP-PIPE
|
|
| 10. |
31N6-50230
|
[3] |
CLAMP-PIPE
|
|
| 11. |
32E1-1025
|
[3] |
CLAMP-PIPE
|
|
| 11. |
31Q6-66250
|
[3] |
CLAMP-PIPE
|
|
| 12. |
E231-0207
|
[1] |
ELBOW-45
|
|
| 13. |
E231-0349
|
[1] |
ELBOW-90
|
|
| 14. |
E131-0625
|
[2] |
CONNECTOR
|
|
| 15. |
E131-0626
|
[1] |
CONNECTOR
|
|
| 16. |
31N5-50220
|
[10] |
SPACER-PIPE
|
|
| 17. |
S109-100356
|
[8] |
BOLT-SOCKET
|
|
| 18. |
S035-062026
|
[12] |
BOLT-W/WASHER
|
|
| 19. |
S017-16070A
|
[10] |
BOLT-HEX
|
|
| 20. |
S411-160006
|
[10] |
WASHER-SPRING
|
|
| 21. |
P173-120102
|
[4] |
FLANGE-HYD,SPLIT
|
|
| 22. |
Y171-019004
|
[2] |
O-RING
|
|
| 23. |
S301-103525
|
[3] |
PLATE-RUBBER
|
|
| 24. |
S301-403030
|
[3] |
PLATE-RUBBER,2HOLE
|
|
| 25. |
S651-810002
|
[3] |
NIPPLE-GREASE
|
|
| 26. |
31N5-50210
|
[2] |
SPACER-PIPE
|
|
| 27. |
S621-014001
|
[4] |
O-RING
|
|
| 28. |
S621-018001
|
[2] |
O-RING
|
|
