凯斯零件查询(46) - MCCORMICK-INTERNATIONAL PICK UP RECTANGULAR BALER (1/57-12/63) (63) - CROSS CONVEYOR BACK SHEET AND SUPPORT, FOR NO.46-W BALER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
938 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
664812R1
|
[1] |
|
P
END, twine can top support
|
| . . |
17403R1
|
[1] |
BOLT,Hex, 1/4" - 20 x 1/2", Gr 2
|
IH
mach., hex-hd., 1/4-20NC x 1/2" Superseded by part number: 22704R1
|
| . . |
103319
|
[1] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
| 2. |
664813R1
|
[1] |
|
P
SHEET, cross conveyor back
|
| . . |
109084
|
[4] |
NUT,1/4"-20, G5
|
IH
Superseded by part number: 7770
|
| . . |
137352
|
[4] |
|
P
SCREW, mach., slotted-truss-hd., 1/4-20NC x 5/8"
|
