纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (08-035) - WATER SEDIMENTER; FUEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
986 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4. | VI1132121401 | [1] | COVER; UPR, SEDIMENTER ASM | |
| 5. | VI5096230700 | [1] | O-RING | KOBGASKET; UPR COVER, SEDIMENTER |
| 7. | VI5132190200 | [1] | BOLT | KOBPLUG; DRAIN, SEDIMENTER |
| 9. | VI5096300240 | [1] | GASKET | KOBGASKET; DRAIN PLUG & CONNECTOR |
| 34A. | VI8944537460 | [1] | PLUG | KOBPLUG; DRAIN, FUEL FILTER |
| 35. | VI8944163770 | [1] | GASKET | KOBGASKET; DRAIN PLUG Superseded by part number: 77272159, VI8941678860 |
| 36. | VI5136190221 | [1] | RING; BODY TO CASE | |
| 38. | VI5132190210 | [1] | FLOAT | KOBFLOAT; SEDIMENTER |
| 46. | VI9095720140 | [4] | PACKING | KOBGASKET; FUEL PIPE |
| 50B. | VI1097007590 | [2] | CLIP; FUEL PIPE | |
| 50C. | VI1097007600 | [2] | CLIP; FUEL PIPE | |
| 51. | VI0286806200 | [2] | BOLT; CLIP (M6X20 FLANGE) | |
| 56. | VI1132112116 | [1] | CASE; FUEL SEDIMENTER | |
| 62A. | VI9099063251 | [1] | BOLT | KOBBOLT; EYE, FUEL FILTER (M14X29 EYE BOLT) Superseded by part number: 87596570 |
| 62B. | VI5157590270 | [1] | BOLT | KOBBOLT; EYE, FUEL FILTER (M14X29) |
