| 1. |
662144R1
|
[1] |
STRAP
|
IH
hitch clevis upper
|
| 2. |
662145R1
|
[1] |
STRAP
|
IH
hitch clevis lower
|
| . . |
473211R1
|
[2] |
LOCK NUT,5/8"-11, GB
|
IH
NUT, 5/8-11 cd-pltd hex. lock Superseded by part number: 231-42110
|
| . . |
103325
|
[2] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| . . |
413-1044
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-3/4", Gr 5
|
CAS
SCREW, 5/8-11 x 2-3/4 cd-pltd hex-hd cap, for 47 Baler Superseded by part number: 88693
|
| . . |
413-1036
|
[2] |
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
|
CAS
SCREW, 5/8-11 x 2-1/4 cd-pltd hex-hd cap, for 37 Baler Superseded by part number: 88556
|
| 3. |
668406R91
|
[1] |
|
P
PIN, hitch cpt., for 37 Baler
|
| . . |
517843R1
|
[1] |
COTTER PIN
|
IH
PIN, 3/16 quick attachable Superseded by part number: 86000109
|
| . . |
520175R1
|
[1] |
CLIP
|
IH
PIN, 3/16 quick attachable, for 37 Baler Superseded by part number: 1970957C1
|
| . . |
Q1238
|
[1] |
HEADED PIN,3/4" x 3 1/2"
|
IH
PIN, 3/4 x 3-1/2 std-hd, for 37 Baler Superseded by part number: 439-11256
|
| 4. |
667608R92
|
[1] |
SPARE PART
|
IH
HITCH, 47 Baler Superseded by part number: 667608R93
|
| 4. |
667611R92
|
[1] |
|
P
HITCH, 37 Baler
|
| 5. |
668037R1
|
[1] |
SUPPORT
|
IH
STAND, hitch and pickup rope, for 47 Baler, used with P.T.O. drive parts completing package
|
| . . |
12258R1
|
[1] |
WASHER
|
IH
21/32 x 1-1/4 x 11 ga Superseded by part number: 25711R1
|
| 7. |
667614R91
|
[1] |
|
P
PLATE, hitch support, for 37 and 47 Balers w/3 knuckle drive shaft
|
| 7. |
667617R91
|
[1] |
|
P
PLATE, hitch support, for 37 Baler w/2 knuckle drive shaft and engine drive
|
| . . |
15010R1
|
[1] |
CARRIAGE BOLT,Short Sq Nk, 1/2" - 13 x 1", Gr 2
|
IH
BOLT, cge, 1/2 x 1
|
| . . |
102637
|
[1] |
NUT,1/2"-13, G5
|
IH
Superseded by part number: 280431
|
| . . |
103323
|
[1] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| . . |
271556
|
[1] |
WHEEL CYLINDER,Hex, 5/8" - 11 x 1 1/4", Gr 5
|
IH
SCREW, 5/8-11 x 1-1/4 hex-hd cap
|
| . . |
102639
|
[1] |
NUT,5/8"-11, G5
|
IH
Superseded by part number: 280374
|
| 8. |
667622R2
|
[1] |
LEVER
|
IH
hitch
|
| 9. |
667623R1
|
[1] |
BUSHING
|
IH
PIVOT, hitch lever
|
| . . |
17768R1
|
[1] |
BOLT,Hex, 1/2" - 13 x 4 1/2", Gr 2
|
IH
mach, 1/2 x 4-1/2 Superseded by part number: 190256
|
| . . |
474848R1
|
[1] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2 Superseded by part number: 231-4218
|
| . . |
Q5035
|
[2] |
WASHER
|
IH
17/32 x 1 x 16 ga. Superseded by part number: 495-81254
|
| 10. |
165
|
[1] |
SPRING
|
IH
hitch lever Superseded by part number: 165-2
|
| . . |
132-347
|
[1] |
COTTER PIN,1/4" x 1"
|
CAS
Split (Cotter), 1/4" x 1" Superseded by part number: 87401
|
| . . |
432-1216
|
[1] |
COTTER PIN,3/16" x 1"
|
CAS
Pin, Split (Cotter), 3/16" x 1"
|
| 11. |
667625R91
|
[1] |
|
P
PIVOT, hitch, cpt.
|
| . . |
179860
|
[2] |
BOLT,Hex, 7/16" - 14 x 1 1/4", Gr 5
|
IH
SCREW, cpa, 7/16 x 1-1/4 Superseded by part number: 9627887
|
| . . |
664646R1
|
[2] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16 Superseded by part number: 280980
|
| . . |
103322
|
[2] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
LOCK, Ext Tooth, 7/16"
|
| . . |
662560R1
|
[1] |
BOLT,Hex, 1" - 14 x 6 1/2"
|
IH
hitch anchor, 1 NF x 6-1/2 cd-pltd
|
| . . |
427652
|
[1] |
SLOTTED NUT,1"-14, G5
|
IH
NUT, 1-14 C-Z hex. Superseded by part number: 86020752
|
| . . |
Q5036
|
[1] |
WASHER
|
IH
1-1/32 x 1-3/4 x 16 ga Superseded by part number: 86624171
|
| . . |
103388
|
[1] |
COTTER PIN,1/8" x 1 3/4"
|
IH
Pin, Split (Cotter), 1/8" x 1 3/4" Superseded by part number: 87673
|
| 12. |
667628R1
|
[1] |
ANGLE
|
IH
STRAP, anchor hitch pivot
|
| . . |
271560
|
[2] |
PANEL,Hex, 5/8" - 11 x 1 3/4", Gr 5
|
NNA
Superseded by part number: 413-1028, 413-1028, NLS
|
| 13. |
667621R1
|
[1] |
BRACKET
|
IH
hitch support, for 37 and 47 Balers w/3 knuckle drive shaft Superseded by part number: 204109C1
|
| 13. |
667620R1
|
[1] |
BRACKET
|
IH
hitch support, for 37 Baler w/2 knuckle drive shaft and engine drive Superseded by part number: 667620R2
|
| . . |
18496R1
|
[2] |
BOLT,Hex, 1/2"-13 x 1 1/2", G2
|
IH
1/2 x 1-1/2 hex-hd mach Superseded by part number: 179885
|
| 14. |
668758R1
|
[1] |
SPACER
|
IH
hitch plate
|
| 15. |
673164R1
|
[1] |
EXTENSION
|
IH
SECTION ASSY, hitch extension, for 37 Baler w/3 knuckle drive shaft Superseded by part number: 3101505R1
|
| . . |
667927R1
|
[2] |
LOCK NUT,5/8"-11, GB
|
IH
NUT, 5/8-11 hex. Superseded by part number: 231-42110
|
| . . |
550832R1
|
[2] |
WASHER
|
IH
21/32 x 2 x 11 ga Superseded by part number: 80299
|
| 16. |
671095R91
|
[1] |
CHANNEL
|
IH
ASSY, hitch extension, for 37 Baler w/3 knuckle drive shaft Superseded by part number: 671095R92
|
