纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (06-005) - NAME PLATE INSTAL (MACHINE NAME) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
594 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB22T00046F1 | [1] | NAME PLATE INSTAL (REQUIRED) | |
| 1. | YB20T01101P1 | [1] | DECAL | KOBLABEL |
| 3. | YB22T00051P1 | [1] | NAME PLATE | |
| 5. | YY22T00107P1 | [1] | DECAL KIT | KOB |
| 6. | YY22T00108P1 | [1] | DECAL KIT | KOB |
| 7. | YB20T01125P1 | [1] | LABEL | |
| 8. | YB20T01124P1 | [1] | LABEL | |
| 9. | YY20T01162P1 | [1] | LABEL | KOB |
| 10. | YY20T01161P1 | [1] | LABEL | KOB |
| . . | YB22T00046F2 | [1] | NAME PLATE INSTAL | |
| 11. | YB22T00049P1 | [1] | NAMEPLATE | KOBNAME PLATE |
