凯斯零件查询(47) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/63-12/88) (B-60) - PLUNGER CRANK SHIELD ATTACHMENT, POWER TAKE-OFF DRIVE ONLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
434 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
667799R91
|
[1] |
|
P
SHIELD, plunger crank cpt.
|
| . . |
17411R1
|
[2] |
BOLT,Hex, 5/16"-18 X 3/4", G2
|
IH
mach. 5/16 x 3/4 Superseded by part number: 179816
|
| . . |
9635082
|
[2] |
NUT,5/16" - 18, Gr 5
|
NH
5/16
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
Q398
|
[2] |
WASHER
|
IH
11/32 x 7/8 x 16 ga Superseded by part number: 95-61034
|
| . . |
667804R1
|
[1] |
|
P
SUPPORT, plunger shield
|
| 2. |
668768R1
|
[2] |
|
P
BRACKET, plunger crank shield
|
| . . |
131402H
|
[2] |
WASHER
|
IH
11/32 x 9/16 x 16 ga Superseded by part number: 95-81067
|
| . . |
2751367R2
|
[1] |
DECAL
|
IH
PRODUCT GRAPHIC, IH, on front of plunger crank shield Superseded by part number: 2753301R1
|
| . . |
2751271R1
|
[2] |
PRODUCT GRAPHIC
|
IH
International name, on both sides of plunger crank shield
|
