纽荷兰零件查询(E215) - CRAWLER EXCAVATOR (NA) - ASN N6DA21215 (1/06-) (02 -01[00]) - ENGINE MOUNTING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
590 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN02P00025F1 | [1] | ENGINE INSTALLATION | |
| 1. | YN02P01019P1 | [1] | BRACKET | KOB |
| 2. | YN02P01041P1 | [1] | BRACKET | KOB |
| 3. | YN02P01014P1 | [1] | BRACKET | KOB |
| 4. | YN02P01042P1 | [1] | BRACKET | KOB |
| 5. | YN02P01024P2 | [8] | COVER | KOB |
| 6. | YN02P01022P1 | [4] | RUBBER MOUNTING | KOB(BLUE) |
| 7. | YN02P01023P1 | [4] | RUBBER MOUNTING | KOB(BLACK) Superseded by part number: LC02P01033P1 |
| 8. | YT52S00001P1 | [1] | SENSOR,50°C to 120°C | KOBTEMP |
| 9. | ZS18C10030 | [16] | SCREW,Hex, M10 x 30mm | KOBM10 x 30mm |
| 10. | ZS18C18130 | [4] | SCREW,Hex, M18 x 130mm | KOBM18x2.50x130mm |
| 11. | ZN18C18015 | [4] | NUT | KOBM18mm |
| 12. | ZW16H18000 | [8] | WASHER | KOBID 19 x OD 36 x Th 4.5mm |
| 13. | ZW16H10000 | [16] | WASHER | KOBM18mm |
| 14. | VAME219070 | [1] | HOSE | KOBBREATHER 25, 4 x 550mm |
