凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-40) - WARNING LAMP BRACKET AND SOCKET Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
188 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
363919R1
|
[1] |
SOCKET
|
IH
lamp, replaces 624341R1 Superseded by part number: 398976R1
|
| . . |
Q397
|
[2] |
WASHER
|
IH
11/32 x 3/4 x 16 ga Superseded by part number: 95-81069
|
| 2. |
660510R1
|
[1] |
|
P
BRACKET, warning lamp
|
| 3. |
660508R1
|
[4] |
|
P
CLIP, warning lamp cable
|
| 4. |
660512R91
|
[1] |
|
P
SOCKET W/ATTACHING PARTS, safety lamp
|
| . . |
668746R92
|
[1] |
|
P
SET, product graphic decal
|
| . . |
2751271R1
|
[2] |
PRODUCT GRAPHIC
|
IH
International decal, replaces 2751051R1, (1) rear cross conveyor cover, (1) cross conveyor side sheet PRODUCT GRAPHICS DECALMANIAS
|
| . . |
2750078R1
|
[2] |
PRODUCT GRAPHIC
|
IH
S, IH Decal, (1) left rear bale chamber side, (1) right rear bale chamber side PRODUCT GRAPHICS DECALMANIAS Superseded by part number: 27776R1
|
| . . |
2754032R1
|
[1] |
PRODUCT GRAPHIC
|
IH
model number decal PRODUCT GRAPHICS DECALMANIAS Superseded by part number: 71812C1
|
