凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-42) - HYDRAULIC BALE TENSION DEVICE, CHANNELS, HOSE AND DRIVE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
619 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
217-42
|
[1] |
REDUCER,3/8" - 18 NPT x 1/4" - 18 NPT
|
CAS
BUSHING, 3/8 x 1/4 zn-pltd reducing pipe
|
| 2. |
668145R91
|
[1] |
|
P
HOSE ASSY, hydraulic
|
| 3. |
144083
|
[1] |
CLIP
|
PA
TEE, 1/4 zn-pltd pipe
|
| 4. |
201603C1
|
[1] |
GAUGE
|
IH
hydraulic tension device, replaces 963008R1 Superseded by part number: 204838C1
|
| . . |
648002
|
[3] |
1/8" x 3/4"
|
KNIFE
|
| . . |
23327R1
|
[2] |
PIN, 5/16 x 1-11/16 C-Z std-hd
|
|
| . . |
21818R1
|
[1] |
|
P
PIN, 3/8 x 1-11/16 C-Z std-hd
|
| 5. |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
ELBOW, 1/4 90 deg pipe zn-pltd street
|
| 6. |
192054
|
[1] |
|
P
NIPPLE, 1/4 x 2-1/2 cd-pltd pipe
|
| 7. |
668124R1
|
[1] |
FRAME
|
IH
hydraulic tension jack
|
| 8. |
668123R1
|
[1] |
CHANNEL
|
IH
hydraulic tension jack
|
| . . |
616254R1
|
[1] |
LOCK PIN,3/8" x 1 5/8", Slotted
|
IH
Pin, 3/8" x 1 5/8", Slotted Superseded by part number: 70918623
|
| 9. |
659422R1
|
[2] |
|
P
BOLT, bale tension channel tie
|
| 10. |
56278D
|
[2] |
CLIP
|
IH
hose attaching loom
|
| 11. |
668136R91
|
[1] |
|
P
CHANNEL ASSY, upper tension
|
| 13. |
668133R1
|
[1] |
SPROCKET ASSY.
|
IH
SPROCKET, driven
|
| . . |
222892
|
[1] |
SCREW,Hex Soc, #10-24 x 1/2"
|
IH
10-24 x 1/2 hex-soc-hd set Superseded by part number: 483-6108
|
| 14. |
668138R91
|
[1] |
|
P
BRACKET ASSY, hydraulic pump
|
| . . |
619856R1
|
[4] |
WASHER
|
IH
13/32 x 1 x 16 ga cd- pltd Superseded by part number: 87613182
|
| 15. |
668142R91
|
[1] |
|
P
SPROCKET ASSY, driver, 48T
|
| 16. |
963095R2
|
[1] |
|
P
SNUBBER, 1/4 NPT pressure
|
