凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-55[A]) - FLYWHEEL SHIELD Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
159 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
657939R11
|
[3] |
|
P
BOLT W/NUTS, flywheel shield U
|
| . . |
120375
|
[6] |
NUT,Hex, 1/4" - 20, Gr 5
|
IH
Superseded by part number: 7770
|
| . . |
492-11025
|
[6] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| 2. |
657940R1
|
[3] |
|
P
CLIP, flywheel shield
|
| 3. |
663622R1
|
[1] |
|
P
SHIELD, flywheel
|
| 4. |
48546DB
|
[1] |
CAP
|
IH
flywheel hub, replaces 49115D
|
| . . |
180056
|
[3] |
BOLT,Hex, 5/16" - 18 x 3/8", Gr 5
|
IH
SCREW, 5/16-18 x 3/8 znd hex-hd cap Superseded by part number: 326-58
|
| . . |
80681
|
[3] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 5. |
200517C1
|
[1] |
|
P
WASHER, flywheel, replaces 663884R1
|
