沃尔沃零件查询MD22A; MD22A-A; MD22L-A; TMD22A; TMD22-A; MS2B-A; MS2B-R; MS2A-E; MS2B-L; MS2L-E; 120S-E; MD22; MD22LCooling SystemSea Water PumpEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
706 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
859824
|
[1] |
Sea water pump
|
|
| 1. |
|
|
|
|
| 2. |
947542
|
[4] |
Flange screw
|
|
| 3. |
859825
|
[1] |
Gasket
|
|
| 4. |
859826
|
[1] |
Adapter
|
|
| 5. |
859821
|
[1] |
Housing
|
|
| 6. |
946470
|
[3] |
Flange screw
|
|
| 7. |
965205
|
[1] |
Flange screw
|
|
| 8. |
859822
|
[1] |
Companion flange
|
|
| 9. |
859823
|
[3] |
Screw
|
|
| 10. |
859809
|
[1] |
Hose
|
Sea water pump-heat exchanger., For TMD22A 868341
|
| 10. |
860130
|
[1] |
Hose
|
Sea water pump-heat exchanger., For TMD22A 868764
|
| 11. |
961669
|
[2] |
Hose clamp
|
|
| 12. |
|
|
|
See group 44
|
| 13. |
|
|
|
See group 44
|
