凯斯零件查询(8580) - CASE IH LARGE RECTANGULAR BALER (1/88-12/98) (09-14) - PLUNGER CLEANER KIT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
389 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700122595
|
[1] |
KIT
|
CAS
PLUNGER CLEANER KIT COMPLETE (S.N. CFH0026001 thru CFH0026135)
|
| 1. |
700122589
|
[1] |
SUPPORT
|
CAS
BLADE WA (Includes item 11) (S.N. CFH0026001 thru CFH0026135)
|
| . . |
700122582
|
[1] |
SUPPORT
|
CAS
BLADE WA (Includes item 11) (S.N. CFH0026136 and later)
|
| 2. |
433-620
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 3. |
495-21044
|
[6] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 4. |
232-5316
|
[8] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 5. |
6232946
|
[4] |
BUSHING
|
CAS
Superseded by part number: 706232946
|
| 6. |
700122587
|
[2] |
SHIN
|
CAS
STRAP
|
| 7. |
700122588
|
[2] |
ANGLE
|
CAS
|
| 8. |
434-616
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 9. |
6518302
|
[2] |
SPACER
|
CAS
|
| 10. |
433-632
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 2", G5 Superseded by part number: 280661
|
| 11. |
740787
|
[2] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
