| 1. |
6526081
|
[2] |
BUSHING
|
CAS
SLEEVE - shear bolt Superseded by part number: 706526081
|
| 2. |
705566
|
[1] |
WASHER
|
IH
3/4 HARDENED PLAIN WASHER
|
| 3. |
6823512
|
[1] |
SPACER
|
CAS
|
| 4. |
700706110
|
[1] |
SPROCKET
|
CAS
- idler, 12 tooth
|
| 5. |
6179246
|
[1] |
BUSHING
|
CAS
|
| 6. |
426-844
|
[1] |
BOLT,Hex, 1/2" - 13 x 2-3/4", Gr 8
|
CAS
Superseded by part number: 86520614
|
| 7. |
231-5348
|
[1] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 8. |
85-15040
|
[2] |
SET SCREW,1/2" - 13 x 2-1/2"
|
CAS
1/2 X 2-1/2 CPSQHSS
|
| 9. |
425-148
|
[2] |
JAM NUT,Jam, 1/2"-13, G5
|
CAS
Superseded by part number: 86632558
|
| 10. |
241-44110
|
[1] |
LINK,Chain, 31.75mm Pitch
|
CAS
CONNECTOR LINK - #100 R/C
|
| 11. |
1795D
|
[1] |
CHAIN (AG)
|
CAS
CHAIN - roller, #100 (10 Foot bulk)
|
| 12. |
7770878
|
[1] |
BOLT,Sq Nk, 1/2" - 13 x 7", Gr 5, Full Thd
|
CAS
1/2-13 X 7 FTRHSNB
|
| 13. |
425-108
|
[8] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 14. |
705541
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 15. |
6526164
|
[1] |
CLEVIS
|
CAS
|
| 16. |
413-1264
|
[1] |
BOLT,Hex, 3/4" - 10 x 4", Gr 5
|
CAS
3/4-10 X 4 C Superseded by part number: 280210
|
| 17. |
492-11075
|
[1] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 18. |
425-1012
|
[1] |
NUT,3/4"-10, G5
|
CAS
3/4-10 H Superseded by part number: 280954
|
| 19. |
495-81205
|
[1] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 X 14 GAUGE NRMB
|
| 20. |
700112933
|
[1] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
| 21. |
700112915
|
[1] |
SPROCKET,40T
|
CAS
ASSEMBLY - 100B40 tooth (Includes items 1, 19 and 20)
|
| 22. |
219-56
|
[1] |
LUBE NIPPLE,90 Degree Elbow, 1/8" - 27 NPTF
|
CAS
1/8-27 X 90 DEGREE ZERK - extended
|
| 23. |
6579106
|
[2] |
LARGE PLATE
|
CAS
CAP - plate Superseded by part number: 706579106
|
| 24. |
700112930
|
[1] |
BUSHING
|
CAS
|
| 25. |
700112906
|
[1] |
ARM
|
CAS
WA
|
| 26. |
7713894
|
[2] |
BEARING, ROLLER, CYL,75 mm ID x 130 mm OD x 25 mm
|
CAS
BEARING - cylindrical Superseded by part number: 605899
|
| 27. |
6526016
|
[1] |
BRACKET
|
CAS
WA - bearing
|
| 28. |
413-12160
|
[1] |
BOLT,Hex, 3/4" - 10 x 10", Gr 5
|
CAS
3/4-10 X 10 B Superseded by part number: 9842687
|
| 29. |
232-41112
|
[1] |
NUT,3/4"-10, GC
|
CAS
NUT, LOCK, 3/4"-10, GC Superseded by part number: 280375
|
| 30. |
700112931
|
[1] |
WASHER
|
CAS
- special
|
| 31. |
700706111
|
[1] |
CIRCLIP
|
CAS
RING - retaining, external
|
| 32. |
413-828
|
[6] |
BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707516, 72187217
|
| 33. |
80679
|
[6] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 34. |
700112909
|
[1] |
HUB
|
CAS
ASSEMBLY (Includes item 1)
|
| 35. |
700112932
|
[1] |
KEY
|
CAS
- straight
|
