凯斯零件查询(8580) - CASE IH LARGE RECTANGULAR BALER (1/88-12/98) (06-30) - TENSIONER ASSEMBLY, KNOTTER HEAD, 6845077 TENSIONER ASSEMBLY COMPLETE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
962 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
6845077
|
[1] |
TENSIONER
|
CAS
ASSEMBLY COMPLETE
|
| 1. |
8701781
|
[2] |
HOUSING
|
CAS
1/2 X 1-1/2 X 3/8-16 HSHSS (Special)
|
| 3. |
425-104
|
[2] |
NUT,1/4"-20, Cl 5
|
CAS
Superseded by part number: 7770, 72187220
|
| 4. |
495-21031
|
[2] |
WASHER,1/4"
|
CAS
1/4 WIDE PLAIN WASHER Superseded by part number: 80701, 72187262
|
| 5. |
7770571
|
[2] |
BOLT,Square, 3/8" - 16 x 6"
|
CAS
3/8-16 X 6 RHSNB - special
|
| 6. |
231-4116
|
[2] |
NUT,3/8"-16, GB
|
CAS
3/8-16 HTLN GR/B Superseded by part number: 88902, E64197
|
| 7. |
495-21044
|
[2] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 8. |
6845135
|
[1] |
PLATE
|
CAS
WA
|
| 9. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 10. |
492-11038
|
[2] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 11. |
6845101
|
[1] |
BRACKET
|
CAS
WA
|
| 12. |
858027
|
[2] |
COMPRESSION SPRING
|
CAS
SPRING - compression
|
| 13. |
6530828
|
[2] |
SPACER
|
CAS
|
| 14. |
8802795
|
[2] |
GEAR
|
CAS
- tension
|
| 2. |
413-420
|
[2] |
BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 87716, 72187191
|
