凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (4-10) - BALE EJECTOR ELECTRICAL ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
650 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
515-2395
|
[5] |
CLAMP,3/8", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86572009
|
| 2. |
121-226
|
[3] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 3. |
329-286
|
[5] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 4. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 5. |
440-1066
|
[2] |
SCREW,Cross Pan Hd, #6-32 x 3/8"
|
CAS
#6-32 X 3/8 CRPHMS GR 60M
|
| 6. |
492-11006
|
[2] |
LOCK WASHER,#6
|
CAS
Washer, Lock, #6 Superseded by part number: 87276
|
| 7. |
700715152
|
[1] |
DECAL
|
CAS
- eject switch
|
| 8. |
700133172
|
[1] |
SUPPORT
|
CAS
- switch
|
| 9. |
700714096
|
[1] |
SWITCH
|
CAS
- rocker
|
| 10. |
66538
|
[1] |
GROMMET
|
CAS
|
| 11. |
515-23190
|
[1] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Line 3/4", Insul, 3/8" Bolt Superseded by part number: 86624005
|
| 12. |
700714114
|
[1] |
HARNESS
|
CAS
- cable, ejector
|
