| 1. |
700716857
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 2. |
529070
|
[1] |
CABLE TIE,368.3mm L
|
NH
TIE - nylon
|
| 3. |
738468
|
[3] |
O-RING
|
IH
|
| 4. |
218-5105
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
(Includes item 3) 90º, 9/16"-18, 37º x 9/16"-18, O-Ring Superseded by part number: 76344, 72186128
|
| 5. |
700712122
|
[1] |
CYLINDER
|
CAS
- hydraulic
|
| 6. |
432-1020
|
[2] |
COTTER PIN,5/32" x 1 1/4"
|
CAS
PIN, SPLIT (COTTER), 5/32" x 1 1/4" Superseded by part number: 86523851
|
| 7. |
439-11032
|
[1] |
HEADED PIN,15.88mm OD x 50.8mm L
|
CAS
5/8 X 2 CLEVIS PIN
|
| 8. |
700134434
|
[2] |
PLATE ASSY.
|
CAS
PLATE- spacer
|
| 9. |
700129085
|
[2] |
CLAMP
|
CAS
|
| 10. |
7846389
|
[1] |
RESTRICTOR
|
CAS
|
| 11. |
1-7141
|
[4] |
FITTING
|
CAS
COUPLING Superseded by part number: 1272770C2
|
| 12. |
433-636
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2 1/4", Gr 5
|
CAS
3/8-16 X 2-1/4 RHSNB Superseded by part number: 280514
|
| 13. |
232-5316
|
[9] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 14. |
121-226
|
[8] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 15. |
515-23254
|
[4] |
CLAMP,1", Insul, 3/8" Bolt
|
CAS
Line 1", Insul, 3/8" Bolt Superseded by part number: 9827902, 72187281
|
| 16. |
700716856
|
[2] |
HOSE
|
CAS
- hydraulic
|
| 17. |
433-656
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3 1/2", Gr 5
|
CAS
3/8-16 X 3-1/2 RHSNB Superseded by part number: 280348
|
| 18. |
329-286
|
[2] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 19. |
237-6010
|
[2] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
|
CAS
10-1, 90 Duro, .755" ID x .097" Thk Superseded by part number: 72186125, 167269
|
| 20. |
218-5135
|
[1] |
ELBOW,45 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
CONNECTOR 45° (Includes item 3) Superseded by part number: 330346
|
| 21. |
700716854
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 22. |
515-25127
|
[14] |
CLAMP,1/2", Insul, 1/2" Bolt
|
CAS
Superseded by part number: 86632595
|
| 23. |
51200289
|
[2] |
FITTING
|
CAS
- hyd (Includes item 19)
|
| 24. |
700716858
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 25. |
63495
|
[1] |
CLIP
|
CAS
5/8 X 2-1/2 CLEVIS PIN
|
| 26. |
700720038
|
[1] |
VALVE
|
CAS
BALE DENSITY CONTROL VALVE Superseded by part number: 700720279
|
